Summary of Contents for NETGEAR FS 726
- Page 1 Modular Fast Ethernet Switch User‘s Guide M O D E L M O D E L...
- Page 2 Trademarks NETGEAR® is a registered trademark of NETGEAR, Inc. in the United States and other countries. All other trademarks and registered trademarks are the property of their respective owners. Statement of Conditions In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice.
- Page 3 • Consult the dealer or an experienced radio/TV technician for help. EN 55024 Declaration of Conformity This is to certify that the NETGEAR Model FS726 Modular Fast Ethernet Switch and Model FS750 Modular Fast Ethernet Switch are shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a.
- Page 4 Defective or damaged merchandise can be returned to your point-of-purchase representative. Internet/World Wide Web NETGEAR maintains a World Wide Web home page that you can access at the uniform resource locator (URL) http://www.NETGEAR.com. A direct connection to the Internet and a Web browser such as Internet...
-
Page 5: Table Of Contents
Media Compatibility and Conversion CHAPTER 4 Installation Preparing the Site Installing the Switch Installing the Switch on a Flat Surface Installing the Switch in a Rack Connecting Devices to the Switch Using Gigabit Ethernet Modules Checking the Installation Applying AC Power... - Page 6 CHAPTER 5 Troubleshooting Information Additional Troubleshooting Suggestions Network Adapter Cards Configuration Switch Integrity Auto Negotiation APPENDIX A Technical Specifications Network Protocol and Standards Compatibility Data Rate Interface Performance Specifications Bandwidth Electrical Specifications Power Consumption Physical Specifications Environmental Specifications Electromagnetic Emissions...
- Page 7 APPENDIX C Cabling Guidelines Fast Ethernet Cable Guidelines Category 5 Cable Category 5 Cable Specifications Twisted Pair Cables Patch Panels and Cables Using 1000BASE-T Gigabit Ethernet over Category 5 Cable Overview Cabling Length Return Loss Near End Crosstalk (NEXT) Patch Cables Conclusion Fiber Optic Cables Fiber Cable Specifications...
- Page 8 Figure 1-1. Package Contents Figure 2-1. Front and Back Panels of the FS726 Switch Figure 2-2. Front and Back Panels of the FS750 Switch Figure 2-3. Creating Redundant Paths between Network Devices (Example 1) Figure 2-4. Creating Redundant Paths between Network Devices (Example 2) Figure 3-1.
- Page 9 Table 1-1. Key Features Table 2-1. Front Panel LEDs Table 4-1. Site Requirements Table 5-1. Troubleshooting Information Table B-1. 10/100 Mbps RJ-45 Plug and RJ-45 Connector Pin Assignments Table B-2. 100/1000 Mbps RJ-45 Plug and RJ-45 Connector Pin Assignments Table C-1. Electrical Requirements of Category 5 Cable Table C-2.
-
Page 10: Chapter 1: Introduction
CHAPTER 1: INTRODUCTION This installation guide describes the NETGEAR FS726 and FS750 Modular Fast Ethernet Switches. NETGEAR’s FS726 and FS750 are expandable, high-performance, IEEE-compliant network switches designed for users who require a large number of ports and want the high-speed capability of 10/100 switching to eliminate bottlenecks, boost performance, and increase productivity. -
Page 11: Features
NETGEAR Model AG711T) or a fiber Gigabit Ethernet module (1000BASE-SX, NETGEAR Model AG711F). (Modules are not included with the switches.) With the advantage of this modularity you can: • Connect switches to each other with high-speed links • Link up to high-speed servers •... -
Page 12: Additional Features
• Automatic address-learning function to build the packet-forwarding information table. The table contains up to 8,000 media access control (MAC) addresses (that is, the switch can support networks with as many as 8,000 devices). • Link speed auto-sensing (10 or 100 Mbps) and duplex mode auto-sensing (half- or... - Page 13 • Compliance with the IEEE802.3i Ethernet, IEEE802.3u Fast Ethernet standards, IEEE802.3ab Gigabit Ethernet, and IEEE802.3z Gigabit Ethernet. • LED indicators to show link, speed, activity, collision, and duplex for switch status and troubleshooting. • Rack Mount Kit for installing the switch in a standard 19-inch equipment rack...
-
Page 14: Package Contents
• Rubber footpads for tabletop installation • Power cord • Rack-mount kit for installing the switch in a 19-inch rack • NETGEAR FS726 and FS750 Modular Fast Ethernet Switch User’s Guide • Support Information Card • Warranty & Owner Registration Card If any item is missing or damaged, contact your place of purchase immediately. -
Page 15: Chapter 2: Physical Description
Switch. Figure 2-2 shows the key components on the front and back panels of the FS750 Switch. The front panel of each switch contains a reset button, an LED Mode push button for alternating LED readout categories, Link LEDs, Mode LEDs, RJ-45 jacks, and two module bays for installing Gigabit Ethernet modules. -
Page 16: Figure 2-1. Front And Back Panels Of The Fs726 Switch
Front Panel of the Model FS726 Switch 10/100 Mbps Module Bays ports Link LEDs Mode LEDs Power LED Mode Reset Button Button Rear Panel of the Model FS726 Switch Power Receptacle Figure 2-1. Front and Back Panels of the FS726 Switch physical description... -
Page 17: 10/100 Mbps Rj-45 Ports
Figure 2-2. Front and Back Panels of the FS750 Switch 10/100 Mbps RJ-45 Ports As Figures 2-1 and 2-2 show, the FS726 Switch has 24 RJ-45 ports, while the FS750 Switch has 48 RJ-45 ports. These are auto-sensing 10/100 Mbps ports: when you... -
Page 18: Led Mode Button And Led Descriptions
Green Yellow physical description Activity Description Power is supplied to the switch. Power is disconnected Port has a valid link connection. A valid link has not been established on the port. Port has made a 100 Mbps connection. Port has made a 10 Mbps connection. -
Page 19: Module Bays
Two module bays on both switches allow you to upgrade as you go, whether you need gigabit uplink or additional port capacity. Each module bay will accept either a copper Gigabit Ethernet module (1000BASE-T, NETGEAR Model AG711T) or a fiber Gigabit Ethernet module (1000BASE-SX, NETGEAR Model AG711F) for high-speed connec- tion to a server, to connect fiber and copper networks, or to extend your network back- bone with high-speed links. -
Page 20: Figure 2-3. Creating Redundant Paths Between Network Devices (Example 1)
Model FS726 Switch FR314 Router Figure 2-3. Creating Redundant Paths between Network Devices (Example 1) Model FS726 Switch EN524 Hub FR314 Router Figure 2-4. Creating Redundant Paths between Network Devices (Example 2) physical description... -
Page 21: Reset Button
To activate the Reset button, insert a small wire, such as a paper clip, into the hole and gently push. As the switch reinitializes, all of the LEDs will extinguish, then light up for approximately one second during the self-test, and then return to their normal state. -
Page 22: Chapter 3: Applications
1000 Mbps access to a file server. A full-duplex adapter card installed in the server can provide 2000 Mbps full-duplex connection. 1000 Mbps 100 Mbps 10 Mbps Model FS726 Switch Figure 3-1. Example of Desktop Switching Server Model FS750 Switch Server... -
Page 23: Segment Switching And Bridging From 10 Mbps To 100 Mbps
The FS726 and FS750 Switches can be used to segment a network into multiple con- nected pieces to increase overall bandwidth and throughput. Both switch models can segment networks that are built with the NETGEAR DS508 and EN516 hubs, and can act as bridges connecting traditional 10BASE-T Ethernet networks to 100BASE-TX Fast Ethernet networks. -
Page 24: Figure 3-3. Example Of Media Compatibility And Conversion
Model FS518 Activity PORT 10/100Mbps Fast Ethernet Switch On = Link Green=FDX,Yellow+COL with Gigabit Ports Activity Normal/Uplink Power Green = FDX,Yellow = COL Figure 3-3. Example of Media Compatibility and Conversion Model FS726 Model FS509 MODEL FS518T Switching PORT Fast Ethernet Switch... -
Page 25: Chapter 4: Installation
CHAPTER 4: INSTALLATION This chapter describes the installation procedures for the NETGEAR FS726 and FS750 Switches. Topics include: • Preparing the site • Installing the switch • Connecting devices to the switch • Checking the installation • Applying AC power... -
Page 26: Preparing The Site
Operating conditions: Keep the switch at least 6 ft (1.83 m) away from nearest source of electro magnetic noise, such as a photocopy machine. After confirming that your site meets the requirements in Table 4-1, you are ready to install the switch. -
Page 27: Installing The Switch
Installing the Switch You can install the NETGEAR FS726 and FS750 Switches on a flat surface or in a standard 19-inch rack. Installing the Switch on a Flat Surface 1. The switch ships with four self-adhesive rubber footpads. Affix one rubber footpad on each of the four concave spaces on the bottom of the switch. -
Page 28: Figure 4-2. Connecting Devices To The Switch
(for more information about Auto Link‘ technology, refer to "Auto Uplink " on page 12). 7. Connect each device to an RJ-45 network port on the switch’s front panel (see Figure 4-2). Use Category 5 (Cat5) unshielded twisted-pair (UTP) cable terminated with an RJ-45 connector to make these connections. -
Page 29: Using Gigabit Ethernet Modules
Using Gigabit Ethernet Modules The modularity of the FS726 and 750 Switches provides you with a highly adaptable network.. You not only can configure your network for copper and/or fiber gigabit uplinks, but you also can opt to expand your network gradually and affordably, as needed. Installing a Gigabit Ethernet module: a. -
Page 30: Checking The Installation
AC power is by connecting or disconnecting the power cord. Before you connect the power cord, select an AC outlet that is not controlled by a wall switch, which can turn off power to the switch. After you select an appropriate outlet, use the following procedure to apply AC power. - Page 31 installation...
-
Page 32: Chapter 5: Troubleshooting
CHAPTER 5: TROUBLESHOOTING This chapter provides guidance in troubleshooting the NETGEAR FS726 and FS750 Switches. Information includes: • Troubleshooting information table • Additional troubleshooting suggestions Troubleshooting Chart Table 5-1 lists symptoms, causes, and solutions of possible problems. Table 5-1. Troubleshooting Chart... - Page 33 File transfer is slow or Half- or full-duplex setting on performance degradation the switch and the connected is a problem. device are not the same. A segment or device is One or more devices are not...
-
Page 34: Additional Troubleshooting Suggestions
Ethernet limitations. Switch Integrity If required, verify the integrity of the switch by resetting the switch. To reset the switch, remove AC power from the switch and then reapply AC power. If the problem continues, contact NETGEAR technical support. In North America, call 1-888-NETGEAR. If you are outside of North America, please refer to the support information card included with your product. -
Page 35: Appendix A: Technical Specifications
APPENDIX A: TECHNICAL SPECIFICATIONS This appendix provides technical specifications for the NETGEAR FS726 or FS750 Switches. Network Protocol and Standards Compatibility ISO/IEC 802-3i 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab 1000BASE-T IEEE 802.3z 1000BASE-SX IEEE 802.3x Flow Control Data Rate 10 Mbps differential Manchester encoded, IEEE 802.3... -
Page 36: Performance Specifications
Performance Specifications Frame filter rate: 14,800 frames/second, maximum on 10 Mbps port (64B packets) 148,000 frames/second, maximum on 100 Mbps port (64B packets) 1,480,000 frames/second, maximum on 1000 Mbps port (64B packets) Frame forward rate: 14,800 frames/second, maximum on 10 Mbps port (64B packets) 148,000 frames/second, maximum on 100 Mbps port (64B packets) -
Page 37: Electrical Specifications
Electrical Specifications FS726 Power Consumption: 40W maximum Physical Specifications FS726 Dimensions: W 440 mm (17.3") D 205 mm (8.1") H 43 mm (1.6") Weight: 3.2 Kg (7.0 lbs) Environmental Specifications Operating temperature: Storage temperature: Operating humidity: Storage humidity: Operating altitude: Storage altitude: FS750 60W maximum... -
Page 38: Electromagnetic Emissions
Electromagnetic Emissions Meets requirements of: CE mark, commercial FCC Part 15, Subpart B, Class A EN 55024 (CISPR 22), Class A VCCI Class 1A C-tick Electromagnetic Susceptibility CE mark, commercial Electrostatic discharge (ESD): Radiated electromagnetic field: Electrical fast transient/burst: Electrical surge: Safety Agency Approvals CE mark, commercial UL/cUL listed (UL 1950) -
Page 39: Appendix B: Connector Pin Assignments
APPENDIX B: CONNECTOR PIN ASSIGNMENTS This appendix provides information about the RJ-45 plug and the RJ-45 connector used for the NETGEAR FS726 and FS750 Switches. RJ-45 Plug and RJ-45 Connector In a Fast Ethernet network, it is important that all 100BASE-T certified Category 5 cabling use RJ-45 plugs. -
Page 40: Table B-1. 10/100 Mbps Rj-45 Plug And Rj-45 Connector Pin Assignments
Table B-1 lists the pin assignments for the 10/100 Mbps RJ-45 plug and the RJ-45 connector. Table B-1. 10/100 Mbps RJ-45 Plug and RJ-45 Connector Pin Assignments Normal Assignment Input Receive Data + Input Receive Data – Output Transmit Data + Output Transmit Data –... -
Page 41: Duplex Sc Plug And Duplex Sc Connector
Duplex SC Plug and Duplex SC Connector The duplex SC connector connects stations, hubs, and switches that support the 1000BASE-SX fiber interface. Each fiber link needs a clearly defined, external crossover. In other words, the transmit port of one interface must be wired to the receive port of the opposite interface and vice versa. -
Page 42: Appendix C: Cabling Guidelines
APPENDIX C: CABLING GUIDELINES This appendix provides specifications for cables used with the FS726 and FS750 Switches. Fast Ethernet Cable Guidelines Fast Ethernet uses UTP cable, as specified in the IEEE 802.3u standard for 100BASE-TX. The specification requires Category 5 UTP cable consisting of either two-pair or four- pair twisted insulated copper conductors bound in a single plastic sheath. -
Page 43: Category 5 Cable
Category 5 Cable Category 5 distributed cable that meets ANSI/EIA/TIA-568-A building wiring standards can be a maximum of 328 feet (ft) or 100 meters (m) in length, divided as follows: • 20 ft (6 m) between the hub and the patch panel (if used) •... -
Page 44: Category 5 Cable Specifications
Computers and workstation adapter cards are usually media-dependent interface ports, called MDI or uplink ports. Most repeaters and switch ports are configured as media-dependent interfaces with built-in crossover ports, called MDI-X or normal ports. Auto Uplink connection, MDI or MDI-X, is needed and makes the right connection. -
Page 45: Figure C-1. Straight-Through Twisted-Pair Cable
Figure C-1 illustrates straight-through twisted pair cable. Key: A = Uplink or MDI port (as on a PC) B = Normal or MDI-X port (as on a hub or switch) 1, 2, 3, 6 = Pin numbers Figure C-1. Straight-Through Twisted-Pair Cable Figure C-2 illustrates crossover twisted pair cable. -
Page 46: Figure C-3. Category 5 Utp Cable With Male Rj-45 Plug At Each End
If you are using patch panels, make sure that they meet the 100BASE-TX requirements. NETGEAR recommends Category 5 UTP cable for all patch cables and work area cables to ensure that your UTP patch cable rating meets or exceeds the distribution cable rating. -
Page 47: Cabling
Cabling The 1000BASE-T product is designed to operate over Category 5 cabling. To further enhance the operation, the cabling standards have been amended. The latest standard is Category 5e, which defines a higher level of link performance than is available with Category 5 cable. -
Page 48: Near End Crosstalk (Next
Factors that affect the return loss are: • The number of transition points, as there is a connection via an RJ-45 to another connector, a patch panel, or device at each transition point. • Removing the jacket that surrounds the four pairs of twisted cable. It is highly recommended that, when RJ-45 connections are made, this is minimized to 1-1/4 inch (32 mm). -
Page 49: Fiber Optic Cables
Fiber Optic Cables In North America, use EIA-569-A horizontal 62.5/125 µm multimode optical fiber cable (ANSI/EIA/TIA-492AAAA). Internationally, use ISO/IEC 11801 62.5/125 µm multimode optical fiber cable (IEC 793-2 type A1b, with 1.0db/km attenuation and 500 MHz/km bandwidth). Refer to Table C-2 for the minimum requirements of fiber optic cable. Fiber Cable Specifications Table C-2 lists the electrical requirements of fiber cable. -
Page 50: Index
Installation Preparing the Site, 4-2 Installing the Switch, 4-3 Installing the Switch on a Flat Surface, 4-3 Installing the Switch in a Rack, 4-3 Connecting Devices to the Switch, 4-4 Checking the Installation, 4-6 Applying AC Power, 4-6 Interface, A-1... - Page 51 Environmental Specifications, A-3 Electromagnetic Emissions, A-4 Electromagnetic Susceptibility, A-4 Safety Agency Approvals, A-4 Performance Specifications, A-2 Troubleshooting Troubleshooting Chart, 5-1 Additional Troubleshooting Suggestions, 5-3 Network Adapter Cards, 5-3 Configuration, 5-3 Switch Integrity, 5-3 Auto Negotiation, 5-3 Twisted Pair Cables, C-3...
- Page 52 NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 USA Phone: 1-888-NETGEAR www.NETGEAR.com M-FS700NA-0 July 2001...
