Summary of Contents for NETGEAR FS524NA
-
Page 2: Start Here
Start Here ™ The NETGEAR Model FS516 16-Port Fast Ethernet Switch and Model FS524 24-Port Fast Ethernet Switch provide you with a low-cost, high-performance network solution and are designed to support power workgroups operating at either 10 megabits per second (Mbps) or 100 Mbps. -
Page 3: Package Contents
• Normal/Uplink push button to simplify network extension The switch can be connected to a hub using a simple, straight-through cable. • Protocol independence and compatibility with all common protocols such as TCP/IP, NetWare, DECnet, and Microsoft Networks • Vista RJ-45 network ports with built-in LEDs to monitor individual port status Package Contents Model FS516 or Model FS524 switch... -
Page 4: Product Illustration
Product Illustration Front Panel The front panel of the Model FS516/FS524 switch contains the following LEDs that correspond to each network port located on the hub: Rx/Tx/Collision and 100 Mbps. Each vista RJ-45 network port has its own Link LED (located at the top left corner of each 10/100 Mbps port), and full-duplex (FDX) LED (located at the top right corner of each 10/100 Mbps port). -
Page 5: Normal/Uplink Push Button
LEDs The table below describes the activity of the LEDs. Label Color Activity Description Pwr (Power) Green Power is supplied to the switch. Power is disconnected. Rx/Tx/Collision Green Blinking Packet transmission or reception is occurring on the port. The blinking action corresponds to the number of packets that are transmitted or received. -
Page 6: Rear Panel
Rear Panel The rear panel of the Model FS516/FS524 switch has full-duplex (FDX) and auto-duplex (AUTO) toggle switches, fans for cooling, and a standard AC power receptacle for the supplied power cord. Rear Panel of the Model FS516 Switch Enable port to determine duplex mode automatically AUTO - FDX - Force port to operate at Full Duplex and Half Duplex mode only... - Page 7 The Model FS516/FS524 switch is used to segment a network into multiple connected pieces, increasing overall bandwidth and throughput. Both switch models can segment networks that are built with the NETGEAR Model DS508 and Model EN516 hubs and can function as bridges connecting traditional 10BASE-T Ethernet networks to 100BASE-TX Fast Ethernet networks.
-
Page 8: Prepare The Site
Prepare the Site Before you begin installing your switch, prepare the installation site. Make sure your operating environment meets the operating environment requirements of the equipment. Characteristic Requirement Temperature Ambient temperature between 0 and 40 C (32 and 104 F). No nearby heat sources such as direct sunlight, warm air exhausts, or heaters. -
Page 9: Connect Devices To The Switch
Connect Devices to the Switch Before connecting the switch, be sure you review “Applications” for information about determining the appropriate configuration for your networking needs. To connect the switch: 1. Connect the devices to the 10/100 Mbps ports on the switch, using Category 5 UTP cable and an RJ-45 plug. -
Page 10: Twisted Pair Cables
Twisted Pair Cables For two devices to communicate, the transmitter of each device must be connected to the receiver of the other device. The crossover function is usually implemented internally as part of the circuitry in the device. Most ports on switches and repeaters have media-dependent interfaces with crossover ports. -
Page 11: Verify Installation
Make sure the 10/100 Mbps port is set to auto- slow or setting on the duplex (AUTO) mode when connecting the performance NETGEAR switch switch to a repeater or hub. degradation is a and the connected problem. device are not the same. -
Page 12: Technical Specifications
Technical Specifications General Specifications Model FS516 Fast Ethernet Switch Model FS524 Fast Ethernet Switch Network Protocol and ISO/IEC 802-3 (ANSI/IEEE 802.3i) 10BASE-T Ethernet IEEE 802.3u,100BASE-TX Fast Ethernet Standards Compatibility Data Rate 100 Mbps with 4B/5B encoding and MLT-3 physical interface for 100BASE-TX 10 Mbps differential Manchester encoded Interface RJ-45 connector for 10BASE-T or 100BASE-TX Ethernet interface... - Page 13 In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
- Page 14 Canadian Department of Communications Radio Interference Regulations This digital apparatus (NETGEAR Model FS516/FS524 Fast Ethernet Switch) does not exceed the Class A limits for radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.
- Page 15 NETGEAR, Inc. A Bay Networks Company 4401 Great America Parkway Santa Clara, CA 95054 USA Phone: 888-NETGEAR http://WWW.NETGEARinc.com *m-fs500na-0* Model FS516/FS524 Fast Ethernet Switch Installation Guide...
