• CENTER: Determine the distance between the axis of the loudspeaker and the microphone
(placed at right angle). The on-axis position (0%) allows the maximum amount of treble fre-
quencies which are highly directional. Moving the microphone away from the axis decreases
the treble, resulting in an enhancement of bass response. At maximum position (100%), the mi-
crophone is placed at the edge of the speaker when Distance is 0%, and 1 meter (3 feet) away
from the axis when Distance is 100%.
• POSITION: in standard sound capture, the microphone is usually placed in front of the cabinet.
However, placing the microphone behind the cabinet can be quite interesting. The sound is
usually softer and darker. This is particularly obvious with closed cabinet, less with open ones.
5.3 EQ
This is a simple yet powerful 5-band EQ. Changing the mode (guitar or bass) shifts the band frequen-
cies to focus on the interesting signal frequencies for the corresponding instrument.
• EQ On: Activate the EQ filter.
• GUITAR | BASS: Guitar or Bass, EQ presets to fit the center frequencies with the instrument you
play.
• 120Hz, 360Hz, 800Hz, 2000Hz, 6000Hz (Guitar mode): center frequency of each band, from the
lower to the higher. The frequencies depend on the mode, Guitar or Bass. You can adjust the
level in dB of each band.

6 SETUP mode

Bouton
SETUP
PRESET/PARAMETER
OUT LEVEL/VALUE
HOLD TO SAVE/EDIT (hold)
HOLD TO SAVE/EDIT (toggle)
Whether you are in EDIT or PERFORM mode, click on the SETUP button to enter the SETUP mode.
The SETUP mode groups all the global parameters of the TORPEDO Live. In this mode, you will gain
access to some information, such as the reception of a MIDI command or the syncing of the machine
with the TORPEDO Remote.
Two Notes Audio Engineering
Configuring and using the TORPEDO Live
Fonction
Return to PERFORM mode
Navigate the parameters
Set a parameter value
Save a preset between 01 and 00 (preset 100)
Switch to EDIT mode
TORPEDO Live 22
