Description

Front View

1
2
3
4
1.LCD
2.OPEN
3 .DISC COVER
4.PLAYBACK BUTTONS
PLAY/POWER ON( )
SKIP-PREVIOUS/FAST REVERSE(
SKIP-FORWARD/FAST FORW ARD(
PAUSE /STEP( / )
STOP/POWER OFF( )

Left View

2
5
6
7
8
5.LCD on/off switch
6.CURSOR(UP/DOWN/LEFT/ RIGHT),
ENTER( )
7 .MENU/PBC
8 .DISPLAY
/ )
/ )
1
N N
P E P E
O O
1.LED LIGHT/REMOTE
CONTROL SENSOR
2. USB Slot

Right View

1
2
1.OPEN
2. EARPHONE / SPEAKER VOLUME
3 .DC IN 12V
4.POWER ON/OFF
5.VIDEO IN

Bottom View

1
2
1.RELEASE LATCH (Battery
pack separation switch)
2.BATTERY PACK
3.SPEAKER
~ 4 ~
O O P E P E
N N
6.AUDIO IN/OUT
7.VIDEO OUT
8.SPDIF: Digital audio signal
output jack
9. EARPHONE JACK
