Wieland xr5i v2 User Manual

Lan-tolan vpn-router
Hide thumbs
Table of Contents

Advertisement

Quick Links

wienet
LAN-toLAN VPN-Router
XR5i v2
USER'S GUIDE
Dok.-Nr. BA000818
Stand: 01/2012 (Rev. A)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the xr5i v2 and is the answer not in the manual?

Questions and answers

Related Manuals for Wieland xr5i v2

Summary of Contents for Wieland xr5i v2

  • Page 1 XR5i v2 LAN-toLAN VPN-Router USER'S GUIDE Dok.-Nr. BA000818 Stand: 01/2012 (Rev. A)
  • Page 2 Copyright Act. Alteration or abridgement of without the express written consent of Wieland Electric GmbH. wienet is a trademark of Wieland Electric. Other names may in this assembly manual men- tioned product and brand- trademarks or registered trademarks of their respective owners could be used, whose use by third parties for their own purposes could violate the rights of the owners.
  • Page 3 Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 4: Table Of Contents

    Technical parameters of I/O port ................27 Technical parameters of expansion port ..............27 Recommended literature ................28 Possible problems ..................29 FAQ ........................ 30 Customers support ..................31 List of figures ....................32 List of tables....................33 Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 5: About This Docoment

    The installation instructions accompanying the product is downloadable in the electronic catalog of Wieland. Be sure to always use the informati- on provided in the current version of this installation manual. The version and revision level can be seen in the title page and the footer.

  • Page 6: Symbols And Notations

    Refer to notes for special features of a device. Instructions also tell you about a potentially harmful situation. If it is not avoided, the sys- tem can be damaged or something in their environment. Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 7: Safety Instructions

    For any other use, or changes to the equipment - even in the context of mounting and installation - any warranty claim against Wieland Electric Gmb expired. Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 8: Router Description

    Router description Introduction Industrial router wienet XR5i v2 is used to a secure connection of two local networks (LAN) via two Ethernet interfaces 10/100. Connection is secured by use tunnels IPSec, wienet OpenVPN or L2TP. The other use of XR5i v2 is converter from serial line RS232, RS485, M-BUS...

  • Page 9: Contents Of Package

    NOTICE In addition to the basics it is possible to deliver:  one or two expansion ports RS232, RS485/RS422, ETHERNET, M-BUS or CNT. Separa- tion columns for mounting expansion boards are included. Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 10: Routerdesign

    83.041.0005.0 Port1: second Ethernet 10/100 MBit/s Port metal version 83.041.0005.1 Mobile EDGE Router wienet ER75i v2 RS232 Such as 83.041.0000.x plastic version 83.041.0001.0 Port1: serial interface RS-232 metal version 83.041.0001.1 Wieland Electric | BA000818 | 01/2012 (Rev. A)
  • Page 11 Such as 83.041.0020.x plastic version 83.041.0022.0 Port1: serial interface RS-485/422 metal version 83.041.0022.1 Mobile UMTS Router wienet UR5 v2 MBus Such as 83.041.0020.x plastic version 83.041.0023.0 Port1: M-Bus interface metal version 83.041.0023.1 Wieland Electric | BA000818 | 01/2012 (Rev. A)
  • Page 12 Such as 83.041.0040.x plastic version 83.041.0042.0 Port1: serial interface RS-485/422 metal version 83.041.0042.1 Mobile HSPA+ Router wienet UR5i v2 MBus Such as 83.041.0040.x plastic version 83.041.0043.0 Port1: M-Bus interface metal version 83.041.0043.1 Wieland Electric | BA000818 | 01/2012 (Rev. A)
  • Page 13 LAN-to-LAN Router wienet XR5i v2 RS485/422 Such as 83.041.0060.0 plastic version 83.041.0062.0 Port1: serial interface RS-485/422 metal version 83.041.0062.1 LAN-to-LAN Router wienet XR5i v2 MBus Such as 83.041.0060.0 plastic version 83.041.0063.0 Port1: M-Bus interface metal version 83.041.0063.1 Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 14: Basic Dimensions Plastic Box

    GSM, GPRS, EDGE, UMTS, HSPA+; rod lenght: 300 mm; inclusi- ve stainless steel mounting bracket; with cable 5 m Basic dimensions plastic box Fig 2: Basic dimensions plastic box Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 15: Basic Dimensions Aluminium Box

     all signals to sensors must be twisted pairs Fig 4: cable routing Cable routing for plastic version Cable routing for metal version  sufficient space must be left before individual connectors for handling of cables CAUT IO N Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 16: Fig 5: Space In Front Connectors

     for correct function of the router we recommend to use in the switch-board earth- bonding distribution frame for grounding of power supply of router, data cables and an- tenna CAUT IO N Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 17: User Interfaces (Connectors)

    Connector– for connection the devices with the router, USB supports equipments with PL-2303 and FTDI USB/RS232 con- verter. 3-pin Connector for connection of the binary input and output. Fig 6: Front panel XR5i Fig 7: Front panel XR5i v2 SL Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 18: Status Indication

    Front Yellow Network cable is connected Blinking: Data transmission Off: Network cable is not connected Front Green PORT Description by Port (viz. Technical specification) Front Yellow PORT Description by Port (viz. Technical specification) Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 19: Power Connector Pwr

    (See bellow picture) Fig 9: connection of power supply connector Circuit example: Fig 10: connection of power supply NOTICE The positive pole VCC is marked by a red socket on the power. Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 20: Ethernet Port

    RXD (+) Receive Data - positive pole Input/Output RXD (-) Receive Data - negative pole Input/Output Fig 11: Ethernet connector ATTENTION! Port ETH is not POE (Power Over Ethernet) compatible! CAUT IO N Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 21: Fig 12: Connection Ethernet Cable

    Routerdesign NOTICE Ethernet cable plug into the RJ45 connector labeled as ETH. (See bellow picture) Fig 12: connection Ethernet cable The Ethernet router connection: Fig 13: example of router connection Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 22: Port1

    USB data + USB data signal - positive pole Input/Output Negative pole of 5V DC supply voltage Fig 15: USB connector NOTICE Example of connecting devices with serial interface to the USB router: Fig 16: connection PLC to the router Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 23: I/O Port

    Connector I/O cable connect into the I/O connector on the router head and tighten locking screws. (See bellow picture) Fig 19: Connection I/O cable NOTICE Circuit example of a binary input or output equipment with router: Fig 20: Connection input and output of router Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 24: Reset

    For pressing the RST button could be used a narrow screwdriver. Fig 21: Router reset NOTICE We recommend to backup your router configuration (See configuration guide), because reset router set configuration to the initial state. Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 25: First Use

    Connecting the router before first use Before you give up the router, it is necessary to connect all components needed for the operation of your applications (See bellow picture). Fig 22: Router connection Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 26: Start Router

    192.168.1.1. Configuration may be performed only by the user "root" with initial password "root". NOTICE A detailed description of the router settings via the Telnet interface can be found in the configuration guide. Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 27: Technical Parameters

    1,4 V Binary output 120 mA / max. 30 V Technical parameters of expansion port Technical parameters of the expansion ports are to be found in separate manuals for ex- pansion ports. Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 28: Recommended Literature

    Recommended literature Recommended literature [1] Wieland: Start guide, [2] Wieland: Configuration manual VPN-Router, [3] Wieland: Technical note WIE-SERVICE24 VPN Portal configuration Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 29: Possible Problems

    It is possible to solve this problem in the following steps:  hand by selection communication rates 10 MB/s in property network cards,  connect router over switch,  start computer only after finalizing the start of the router. Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 30: Faq

    Verify present the expansion port RS232 in router configuration in menu „external port“, or verify connection locally by the help Telnet-Hyper terminal.  L2TP or IPSec isn’t establishing.  Verify the reason in the log system. Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 31: Customers Support

    Up to date information about the product is on website: http://www.wieland-electric.com/ http://eshop.wieland-electric.com/ Upkeep-advices: Admission: Wieland Electric hereby declares that the router narrated in this user’s guide fits all basic demands of directive 1999/5/EC (R&TTE). Wieland Electric | BA000818 | 01/2012 (Rev. A)

  • Page 32: List Of Figures

    Fig 4: cable routing....................... 15 Fig 5: space in front connectors ................... 16 Fig 6: Front panel XR5i v2 ....................17 Fig 7: Front panel XR5i v2 SL ....................17 Fig 8: Power connector ......................19 Fig 9: connection of power supply connector..............19 Fig 10: connection of power supply ..................

  • Page 33: List Of Tables

    Table 8: USB port ........................22 Table 9: I/O port........................23 Table 10: Reset/Reboot ......................24 Table 11: Technical parameters router..................27 Table 12: Technical parameters of processor ...............27 Table 13: Technical parameters I/O port ................27 Wieland Electric | BA000818 | 01/2012 (Rev. A)
  • Page 34 Wieland Electric | BA000818 | 01/2012 (Rev. A)
