DSC Maxsys PC4010 Programming Manual page 44

If the reporting code is left as default FF, the RC (reporting code) will be the same as the zone
number and the FB (function byte) for the zone events will be chosen form the corresponding
zone type. A zone has 7 associated events that will modify the printer MSG:
PC4010 Event
Zone Alarm
Zone Restore
Partial Closing+ Zone Alarm
Zone Trouble/Tamper
Zone Trouble/Tamper Restore
Zone Fault
Zone Fault Restore
The following is a list of the default settings for zone transmissions:
Zone Type
Standard Delay
Aux. Delay
Instant
Interior
Interior H.A
Delay H.A
24 hr Bell
24 hr Bell/Buzzer
24 hr Buzzer
Standard Fire
Delayed Fire
Auto Ver. Fire
Momentary Arm
Maintained Arm
Latching 24 hr
Forced Answer
Links Supervisory
Links Answer
Sprinkler
Hold Up
Panic
Technical
Enter this section to restore the PC4400 programming back to the default values.
DEFAULT DVAC
Note: When exiting installers mode, if the panel loses communications with the PC4400
(2)
module, the message "DVAC module not present" will be displayed. If this occurs check
your wiring, then enter and exit installers mode again.
FB: Alm Rst Byp
08 88 48
08 88 48
09 89 49
0A 8A 4A
0B 8B 4B
07 87 47
11 91 51
11 91 51
11 91 51
00 80 40
00 80 40
00 80 40
XX
XX
16 96 56
XX
18 98 58
XX
01 81 41
03 83 43
02 82 42
18 98 58
43
DVAC Printer MSG
Alm
Rst
Byp
Trb
T_R
Sup
S_R
Trb T_R Sup S_R
28 A8 68 E8
28 A8 68 E8
29 A9 69 E9
2A AA 6A EA
2B AB 6B EB
27 A7 67 E7
31 B1 71 F1
31 B1 71 F1
31 B1 71 F1
20 A0 60 E0
20 A0 60 E0
20 A0 60 E0
36 B6 76 F6
38 B8 78 F8
21 A1 61 E1
23 A3 63 E3
22 A2 62 E2
38 B8 78 F8
Printer MSG
Delay
Delay
Instant
Interior
InteriHA
DelayHA
24 hr
24 hr
24 hr
Fire
Fire
Fire
24hrLat
Supervi
Sprnklr
Hold Up
Panic
Supervi
