Daikin RKS25F2V1B Technical Data Manual page 11

3 Electrical data
Representative unit combination
Indoor unit Outdoor unit
FTKS50FV1B RKS50F2V1B
1
FTKS60FV1B RKS60F2V1B
3
FTKS71FV1B RKS71FV1B
SYMBOLS
MCA : Min. Circuit Amps (A)
MFA : Max. Fuse Amps (A)
RHz : Rated operating frequency (Hz)
RLA : Rated Load Amps (A)
OFM : Outdoor Fan Motor
IFM : Indoor Fan Motor
FLA : Full Load Amps (A)
W : Rated motor output (W)
11
• Outdoor Units • R-410A • RKS-F2V1B
Power supply
Hz-volts Voltage range
50 - 220
Max. 50Hz 264V
50 - 230
Min. 50Hz 198V
50 - 240
50 - 220
Max. 50Hz 264V
50 - 230
Min. 50Hz 198V
50 - 240
50 - 220
Max. 50Hz 264V
50 - 230
Min. 50Hz 198V
50 - 240
1. RLA is based on the following conditions:
2. Maximum allowable voltage unbalance between phases is 2%
3. Select wire size based on the larger value of MCA.
4. Instead of fuse, use circuit breaker.
5. For more details concerning conditional connections, see
• Split Sky Air • Outdoor Units
Comp.
MCA MFA RHz
19.75 20.0 67
19.75 20.0 84
19.75 20.0 57
NOTES
Indoor temp.: 27°CDB/19.0°CWB
Outdoor temp. : 35°CDB
http://extranet.daikineurope.com, select ''E-Data Books''. Finally, click on
the document title of your choice.
OFM IFM
RLA W FLA W
6.7
6.4 53 0.27 43
6.1
8.7
8.3 53 0.32 43
7.9
10.3
9.9 66 0.40 43
9.4
3D056032A
FLA
0.16
0.16
0.19
