GLOCKENKLANG Blue Rock User Manual

GLOCKENKLANG Blue Rock User Manual

Advertisement

Quick Links

head

User Manual

Contents
Introduction
How to use
1. Input stage with overdrive
function
2. Equalizer
3. Drive section with Voice filter
4. Effects loop
5. Volume control
6. Power stage
7. Mains connection
8. Speaker + phones outputs
9. Balanced DI output
10. Parallel insert loop (mixable)
including MP3 player input
11. Footswitches + Tuner Out
12. DIP-switches for output-
impedance
Technical Data
Warranty
GLOCKENKLANG
Eimterstr. 147
D-32049 Herford
Tel +49-5221-51506
Fax +49-5221-108755
http://www.glockenklang.de
e-mail:
info@glockenklang.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Blue Rock and is the answer not in the manual?

Questions and answers

Summary of Contents for GLOCKENKLANG Blue Rock

  • Page 1: User Manual

    User Manual Contents Introduction How to use 1. Input stage with overdrive function 2. Equalizer 3. Drive section with Voice filter GLOCKENKLANG 4. Effects loop Eimterstr. 147 5. Volume control 6. Power stage D-32049 Herford 7. Mains connection Tel +49-5221-51506 8.
  • Page 2 Thank you for choosing the Care GLOCKENKLANG Blue Rock amplifier. You Use a soft, clean and dry cloth only to have purchased an exquisite piece of clean the amplifier. Do not use aggressive equipment, which was designed after the chemicals to clean the housing. Do not most modern technical aspects.
  • Page 3: Gain Control

    1.1 Input A Jack 2.1 Equalizer with On Switch Normal instrument input for active and passive Bass, Low Mid, Mid, High Mid and Treble instruments. controls serve to fine tune your sound or solve acoustical problems on stage. They will be 1.2 Input B Jack activated by the On Switch.
  • Page 4: Volume Control

    4.1 Effect/MP3 On Switch Activates the Effect Loop ( Parallel Loop ). This feature can also be activated by foot switch. 4.2 Effect/MP3 Gain Control Varies gain of the Effect Return/MP3 In between ±5 dB. 4.3 Effect/MP3 Control Mixes the effects loop into the original signal from 0% ( original signal only) to 100% (effect only) 5.1 Volume Control...
  • Page 5: Phones Jack

    7.1 A/C Connector with fuse 10.1 Loop / MP3 switch Connector for A/C cord. The fuse is located in the Activates the stereo MP3 In function of the Loop small compartment below. A spare fuse is included Return instead of mono Return In. in the compartment, toot.
  • Page 6: Technical Data

    Technical Data Solid state class D powered bass amplifier, 19" rack mountable, 2 rackspaces high. Inputs 1 Jack ¼” A for basses with normal output level, 3 MΩ 1 Jack ¼” B for basses with higher output, additional pre-damping control, 4.7 MΩ Equalization Bass +15dB 60Hz, -15dB 30Hz...
  • Page 7 3. Die Garantie berechtigt nicht zur kostenlosen Inspektion oder § 1 GARANTIE-LEISTUNG Wartung bzw. zur Reparatur des Gerätes, insbesondere wenn 1. Die Firma GLOCKENKLANG gewährt für mechanische die Defekte auf unsachgemäße Benutzung zurückzuführen sind. und elektronische Bauteile des Produktes, nach Maßgabe...
  • Page 8 93/68/EEC and the low voltage Directive 73/23/EEC including amendment 93/68/EEC. This declaration of conformity of the European Communities is the result of an examination carried out by the Qualitiy Assurance Department of GLOCKENKLANG in accordance with European Standards EN 50081-1, EN 50082-1 and EN 60065 for low voltage.
