Reversing The Door Swing - GE zdwc240nbs Owner's Manual

To reverse
To remove the door:
the door
1. Remove 2 screws holding toekick.
2. Remove hinge plug cover on top left
3. Flatten the shipping carton to use as
4. Remove the 3 screws holding the top
5. Lift off case hinge, it will not be used
6. Lift door off bottom case hinge.
7. Remove bottom case hinge and cam
8. Remove fill plug and screw on top right
9. Remove door hinge, door stop and screw
Rotate the door:
Handle will be on right side of door, hinges
will go on the left.
To reinstall the door:
1. Install bottom case hinge from kit and
2. Install door hinge and door stop to
3. Install fill plug on top left of door.
4. Place door on bottom case hinge.
5. Install top case hinge from kit on top
6. Install hinge plug cover on top right
7. Move plug on toekick to opposite side.
8. Install toekick. Verify that spacers are
9. Install Monogram nameplate on door.
10. Put remaining case hinges in bag for
Note: Verify that door is on straight and
screws are tightened. If not, the door
will sag.
Position new nameplate:
Remove the old nameplate and stick the new
Monogram nameplate on the door using the
template included.
side of cabinet.
a pad for the door.
case hinge.
again.
riser.
side of door.
from bottom right side of door.
cam on the left side of the unit.
bottom left of door.
left of cabinet.
of unit.
attached to screw holes.
possible future use.

Reversing the Door Swing

Wine Chiller
Install
3 Hinge
Screws
Hinge
Pin
Remove
Top Hinge
Cam
Riser
Remove
Hinge
