Aiwa TP-VS615 Supplemental Service Manual
Hide thumbs Also See for TP-VS615:

Advertisement

TP-VS615
YU
615
SERVICE MANUAL
CASSETTE RECORDER
BASIC TAPE MECHANISM : ZZM-6 R1NF
• This Service Manual contains information about the difference between
TP-VS615(YU) and TP-VS615(Y).
If requiring other information, see Service Manual of
TP-VS615(YH,Y,YJ,YL), (S/M Code No. 09-007-435-2R2).
S/M Code No. 09-00C-435-2S1
