Manual adjustment of motor end-stops

13
Please, follow this step ONLY if the end of travel of the motors has moved during transit. If your screen
automatically stops at the desired full extension and full winding up, you do NOT need this step.
1 -
Using a screwdriver, push the two buttons in order to free the screen stopping positions.
click
click
2 -
Carefully deploy the screen to the desired position.
Lock this position by releasing the correct button as shown in the table below.
3 -
Carefully define the desired closed position.
Lock this position by releasing the correct button as shown in the table below.
click
Refer to this table if the motor of your screen is mounted on the LEFT
Screen Screen
Model Lock UP
MS2 yellow
MMS2-L1 white
MMS2-T white
MMS2-L2 white
MMS2-4 white
ICMS1 Install Manual : Rev B 01 Apr 2009
Pushed buttons = unlocked screen
No more stop position memorized
Screen Lateral Mask
Lock DOWN Lock UP
white
yellow yellow
yellow
yellow yellow
yellow yellow
click
click
Lateral Mask
Lock DOWN
white
white
white
-6-
click
Released buttons = locked screen
Stop positions are memorized
MAX
LIMIT !
Top Mask
Lock UP Lock DOWN
yellow
yellow
yellow
Top Mask
white
white
white
