Ceiling Mounting

2
Mount the screen into the ceiling as shown below.
Use fixings suitable for load bearing structure

Screen transit locking removal

3
1
*
B
REMOVE REMOVE
B
Horizontal
OR
Masking
Lateral
Masking ONLY
* LM (Lateral Masking) may not be present on your model.
ICMS1 Install Manual : Rev B 01 Apr 2009
L - 6 0
2
CUT CUT
& REMOVE & REMOVE
Lateral
Masking
m m
( 2 3 /
8 " )
L
* BB (Black Backing) layer may not be present on your model.
* M (Masking) may not be present on your model.
CUT
-2-
3
& REMOVE
