Manual Switch Connection

4
Screens with masking require more than one connection.
IMPORTANT
FOR MODELS WITH MASKING
- Use the Reverse adaptor supplied to connect the switch to the screen motor.
Never
-
- Connect plugs matching the color rings (Blue to Blue, Yellow to Yellow).
- Failure to follow this procedure will invalidate any product warranty.
3

Manual Deployment of the Screen

5
click

Removal of Masking Transit Security Screws

6
REMOVE
ICMS1 Install Manual : Rev B 01 Apr 2009
:
use the reverse adaptor to connect switches to the masking motors.
blue
2
blue
Horizontal
Masking
Repeat at each
end of the screen.
ONLY
:
Adaptor
(USE ONLY WHEN A YELLOW RING IS USED ON THE SCREEN MOTOR CONNECTION)
1
Screen motor
yellow
REMOVE
-3-
blue or
yellow
10 cm (4")
Only carry out this
step once all transit
security fixings have
been removed
Lateral
Masking
end of the screen.
Repeat at each
