End Travel Verification (Default set at factory)
7
click
Carefully deploy the screen to its maximum extent.
Verify that it stops automatically at the desired end of travel.
If this is not the case, please proceed to Step
Do not pass the white line
drawn in the black drop zone.
After this point, deployment
of the fabric risks damage to
Important
: As part of the installation procedure it is important that the motor end stops are
verified in order to prevent damage to the screen.
The end stop limits are set at the factory, but may have been released during shipping.
Failure to perform this procedure will void any subsequent claims made under the product
warranty. Please contact Screen Research if you have any questions.
Perform this step for all motors/masks !

MCS Installation

8
Refer to the MCS hardware guide in
order to connect your control devices
correctly.
Receivers
UP
MCS-BRR
(Radio Frequency)
Interfaces
MCS-SIP MCS-BRS
ICMS1 Install Manual : Rev B 01 Apr 2009
13
the product.
MCS (Motor Control Systems) Manual
Remotes
MCS-RR0 MCS-RR1
MCS-BIE MCS-IR0 MCS-IR1
(Infrared)
Motors
MCS-320 MCS-310
click
Carefully stow the screen to its stored position.
Verify that it stops automatically at the desired end of travel.
If this is not the case, please proceed to Step

MCS Configuration - Testing

9
Refer to the MCS software guide
should you wish to reprogram the
motor control system.
-4-
13
MCS (Motor Control Systems) Manual
