FOLDING
THIS MANUAL CONTAINS IMPORTANT SAFETY,
PERFORMANCE AND MAINTENANCE INFORMATION.
READ THE MANUAL BEFORE TAKING YOUR FIRST
RIDE ON YOUR NEW BICYCLE, AND KEEP THE
MANUAL HANDY FOR FUTURE REFERENCE.
To register your bike visit
www.schwinnbikes.com/registerbike

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S14 Folding Bicycle and is the answer not in the manual?

Questions and answers

Summary of Contents for Schwinn S14 Folding Bicycle

  • Page 1 FOLDING THIS MANUAL CONTAINS IMPORTANT SAFETY, PERFORMANCE AND MAINTENANCE INFORMATION. READ THE MANUAL BEFORE TAKING YOUR FIRST RIDE ON YOUR NEW BICYCLE, AND KEEP THE MANUAL HANDY FOR FUTURE REFERENCE. To register your bike visit www.schwinnbikes.com/registerbike...

  • Page 2: Table Of Contents

    Adjusting the Rear Derailleur . . . . . . . . . . . . . . . . . . . . . . 32 Schwinn Folding Bicycle Manual.indb 1...
  • Page 3 . vehicle, bicycle, and traffic laws, but also the common sense rules of safe and responsible bicycling . As a parent, you should Our customer service department is dedicated to your read this manual before letting your child ride the bicycle. Please satisfaction with Pacific Cycle and its products. If you have make sure that your child always wears an approved bicycle questions or need advice regarding assembly, parts, performance, helmet when riding. or returns, please contact the experts at Pacific Cycle. Toll free: 1-800-626-2811 . Customer Service hours: Monday - Friday 8:00 am to 5:00 pm Central Standard Time (CST). Schwinn Folding Bicycle Manual.indb 2 7/1/14 3:58 PM...
  • Page 4 • ALWAYS WEAr A ProPErLY FITTED hELMET WhEN rIDING Your bICYCLE • Do NoT rIDE AT NIGhT • AvoID rIDING IN WET CoNDITIoNS Incorrect Fitting Forehead is exposed and vulnerable to serious injury Schwinn Folding Bicycle Manual.indb 3 7/1/14 3:58 PM...

  • Page 5: Safety

    Indicates a hazard or unsafe practice that could result in • The child understands applicable laws and common sense minor injury. rules of safe responsible bicycling. notiCe Indicates a hazard unrelated to personal injury, such as property damage. Schwinn Folding Bicycle Manual.indb 4 7/1/14 3:58 PM...

  • Page 6: Personal Safety

    Do not wear: • Loose clothing parts, strings, jewelry that may become Leg band entangled with moving parts on the bicycle or interfere with Laces tied handling of the bicycle. Figure 1.1 Schwinn Folding Bicycle Manual.indb 5 7/1/14 3:58 PM...
  • Page 7 The correct helmet should: Figure 1.2 Figure 1.2 • Be comfortable • Have good ventilation • Fit correctly • Cover forehead Incorrect helmet position: Figure 1.3 • Helmet does not cover the forehead Figure 1.3 Schwinn Folding Bicycle Manual.indb 6 7/1/14 3:58 PM...

  • Page 8: Bicycle Setup

    Top tube If the bicycle has a top tube on the frame, check that there is one to three inches of clearance between the rider and the top tube. Figure 1.4 Figure 1.4 Schwinn Folding Bicycle Manual.indb 7 7/1/14 3:58 PM...
  • Page 9 ❸ Ensure the seat post’s minimum insertion marks are not visible above the quick-release seat clamp and the clamp is locked in place. Note: See Section 4: Adjusting the Seat Height if adjustments are needed. Schwinn Folding Bicycle Manual.indb 8 7/1/14 3:58 PM...
  • Page 10 This is unsafe and the bicycle cannot be controlled in this condition. ❷ You should be able to safely reach the handlebar with your arms bent slightly (approximately 10 degrees) at the elbow. Figure 1.6 Schwinn Folding Bicycle Manual.indb 9 7/1/14 3:58 PM...
  • Page 11 5 degrees of vertical. Figure 1.7 • Rear Reflector: Should aim straight back (when viewed from above) and be mounted so it is within 5 degrees of vertical. Schwinn Folding Bicycle Manual.indb 10 7/1/14 3:58 PM...

  • Page 12: Riding Safety

    • Pot holes and slippery surfaces such as line markings and train or stopping. tracks all become more hazardous when wet. • Obey the traffic laws (e.g. stopping at a red light or stop sign, giving way to pedestrians). Schwinn Folding Bicycle Manual.indb 11 7/1/14 3:58 PM...
  • Page 13 • Never take your hands off the handlebars, or your feet off the pedals when riding downhill. • Braking will require additional distance. Initiate braking slowly and earlier than usual. Schwinn Folding Bicycle Manual.indb 12 7/1/14 3:58 PM...

  • Page 14: Bicycle Safety Checklist

    The brake control levers are lubricated and tightly secured pressures displayed on the tires sidewall. to the handlebar. □ The tires have the proper amount of tread, no bulges or excessive wear. Schwinn Folding Bicycle Manual.indb 13 7/1/14 3:58 PM...

  • Page 15: Parts Identification

    Brake pad adjustment screw 50 - 60 Tire valve Spring tension adjusting screw Front wheel axle 180-240 Rear reflector Front wheel reflector Rear wheel reflector Tire Derailleur Spoke Wheel rim Front fender Schwinn Folding Bicycle Manual.indb 14 7/1/14 3:58 PM...
  • Page 16 Parts Identification 2 Schwinn Folding Bicycle Manual.indb 15 7/1/14 3:58 PM...

  • Page 17: Assembly

    If you have questions about your ability to properly assemble this unit, please consult a qualified specialist before riding. Schwinn Folding Bicycle Manual.indb 16 7/1/14 3:58 PM...

  • Page 18: Getting Started

    ❶ Begin by standing on the chain side of the bicycle. The chain and crank will be in front of you. Figure 3.2 ❷ Open the front and rear halves of the frame apart and the halves come together. Figure 3.2 Schwinn Folding Bicycle Manual.indb 17 7/1/14 3:59 PM...
  • Page 19 Latch. Important! It should require some pressure to engage the lock and your hand should have indent marks from the lever. Adjust the quick-release Figure 3.3 lever until it is firmly engaged. Schwinn Folding Bicycle Manual.indb 18 7/1/14 3:59 PM...
  • Page 20 Post Latch. Important! It should require some pressure to engage the lock and your hand should have indent marks from the lever. Adjust the quick-release Figure 3.4 lever until it is firmly engaged. Schwinn Folding Bicycle Manual.indb 19 7/1/14 3:59 PM...

  • Page 21: Attach The Pedals

    Pedal in down position position ❹ If the spindle entered the hole cleanly then use a 15 mm wrench to tighten completely. ❺ Flip the pedals into the down position. Figure 3.6 Figure 3.6 Schwinn Folding Bicycle Manual.indb 20 7/1/14 3:59 PM...

  • Page 22: Attach The Seat

    ❹ Check the seat does not move. Figure 3.7 Note: Riders weight including luggage should not exceed 230 lbs. (105 kg). Schwinn Folding Bicycle Manual.indb 21 7/1/14 3:59 PM...

  • Page 23: Folding The Bicycle

    ❺ Close the quick-release. ❻ Raise the kick stand and rotate the crank arms so that the left crank is pointed forward and down at a 45 degree angle. Figure 3.10 Figure 3.10 Schwinn Folding Bicycle Manual.indb 22 7/1/14 3:59 PM...
  • Page 24 Figure 3.11 parallel. Figure 3.12 ❿ Push the pedal in, and rotate it into the locked position. Repeat for the opposite pedal. Figure 3.13 Fold wheels The bicycle is now ready for transportation or storage. parallel Figure 3.12 Figure 3.13 Schwinn Folding Bicycle Manual.indb 23 7/1/14 3:59 PM...

  • Page 25: Adjustments

    If you have questions pertaining to the assembly of your bicycle, call the service line direct at: 1-800-626-2811. Monday - Friday 8:00 am to 5:00 pm Central Time (CST). Schwinn Folding Bicycle Manual.indb 24 7/1/14 3:59 PM...

  • Page 26: Adjusting The Frame Latch

    ❷ Add a drop of Loc-Tite® glue to the bolt threads to prevent loosening. Do not add Loc-Tite® glue to the hinges. ❸ Periodically lubricate the lever to keep it working smoothly. Figure 4.1 Schwinn Folding Bicycle Manual.indb 25 7/1/14 3:59 PM...

  • Page 27: Adjusting The Handlebar Post Latch

    Turn clockwise to tighten ❹ Add a drop of Loc-Tite® glue to the bolt threads to prevent loosening. Do not add Loc-Tite® glue to the hinges. ❺ Lubricate the mechanism periodically. Figure 4.2 Schwinn Folding Bicycle Manual.indb 26 7/1/14 3:59 PM...

  • Page 28: Adjusting The Seat Height

    Figure 4.3 quick-release lever, hold the base and turn the lever clockwise until you have sufficient force and the seat cannot move. ❹ Check the seat does not move. Schwinn Folding Bicycle Manual.indb 27 7/1/14 3:59 PM...

  • Page 29: Brake Adjustment

    Figure 4.5 ❹ Release the brake lever. Figure 4.6 ❺ Lightly pull on the cable, and rotate the cable nut and cable barrel so they are no longer aligned. Figure 4.6 Schwinn Folding Bicycle Manual.indb 28 7/1/14 3:59 PM...
  • Page 30 1/8” (3 mm) gap between the brake pad and rim. 5 mm allen wrench ❻ Using the 5 mm allen wrench, firmly tighten the cable anchor bolt completely. 1/8” gap (both pads) Wheel rim Figure 4.8 Schwinn Folding Bicycle Manual.indb 29 7/1/14 3:59 PM...
  • Page 31 Retighten the bolt after positioning the pad correctly. Figure 4.9 Incorrect Alignment Even space between wheel and fork correct Alignment (both sides) Wheel should be centered Figure 4.9 Figure 4.10 Schwinn Folding Bicycle Manual.indb 30 7/1/14 3:59 PM...
  • Page 32 If you run out of adjustment capability on both screws do a minor adjustment to the brake cable. Adjustments should be made to each side as equally as possible to prevent running out of adjustment capability. Schwinn Folding Bicycle Manual.indb 31 7/1/14 3:59 PM...

  • Page 33: Adjusting The Rear Derailleur

    ❺ Shift the rear shifter to the gear one and place the chain on the largest cog. ❻ Adjust the low limit screw (L) in quarter turn increments Figure 4.13 until the guide pulley and the largest cog are aligned vertically. Schwinn Folding Bicycle Manual.indb 32 7/1/14 3:59 PM...

  • Page 34: Use

    • Always test the brakes and be sure you feel comfortable with the reaction. If the riding conditions are too steep (off road Hand Operated Brakes for example) and you are unsure, dismount the bicycle and walk past the questionable terrain before riding again. WarnInG! • Remember that as you apply the brakes your weight will want to shift forward, and the wheels will want to stop. If the front brake is applied too quickly or too hard, the front wheel can stop turning resulting in a front pitch over or cause • See Section 4: Brake Adjustments if adjustments are needed. the bicycle to lose steering function leading to a crash. Hand operated brakes have a separate hand lever to operate Press to engage brakes front and rear brakes. Front hand brake levers are located on the left side of the handlebar, and rear hand brake levers are located on the right side of the handlebar. Figure 5.1 It is OK to operate one brake at a time, or all together, depending on your style, comfort, and riding conditions, however, be careful to pay close attention to front brakes locking up. Figure 5.1 Schwinn Folding Bicycle Manual.indb 33 7/1/14 3:59 PM...

  • Page 35: Gear Operation

    Front equipped bicycles, it is important to be pedaling forward when cogs derailleur shifting gears. This allows the chain to “derail” from one gear to the next. Operating the shifter while sitting still or not pedaling Derailleur can cause damage to the system, and can be dangerous, as the control cable chain may jam and cause the bike to become unstable. Figure 5.2 To shift properly, pedal the bicycle with little pressure on the Crank arm pedals, and move the shifter one gear at a time, ensuring that the chain is fully engaged in that gear before applying more Rear Guide Front derailleur pulley chain pressure on the pedals. For bicycles with 3 front chain rings; wheels Pedal avoid “Cross Chaining”, which is the position when the chain is in Figure 5.2 the smallest cog in the rear combined with the inner or smallest chain ring in the front, or the largest cog in the rear and the outer or largest chain ring in the front. These gear positions put the chain at the most extreme angle and can cause premature Schwinn Folding Bicycle Manual.indb 34 7/1/14 3:59 PM...

  • Page 36: Rear Shifter

    • When shifting, lessen the pressure exerted on the pedals • 1 is the lowest gear. This is used for slower riding, hill during the shift. climbing, or to allow for easier pedaling. It is recommended to • Once you have successfully shifted gears, it is OK to start to start off in this gear and move through the gears as speed pedal hard if desired. Pedaling hard while shifting can cause increases as needed, or comfortable. the chain to skip and not engage the appropriate gear • It is OK to ride the whole time in only one gear if this is • Backpedaling should be avoided on derailleur bikes because comfortable. the chain can jam and cause the bike to become unstable. • Turn the left gear shifter handlebar grip up or down to shift See Section 4: Adjusting the Rear Derailleur if adjustments into a new gear. are needed. Gear indicator Shifter Figure 5.3 Schwinn Folding Bicycle Manual.indb 35 7/1/14 3:59 PM...

  • Page 37: Security

    • Maintain a record of the bicycle’s model number, located on the frame. Figure 5.4 • Register the bicycle with the local police and/or bicycle registry. • Invest in a high quality bicycle lock that will resist hacksaws and bolt cutters. • Always lock your bicycle to an immovable object if it is left unattended. Keep in mind that individual parts of a bicycle may be stolen. Most commonly, if you lock just a wheel or Figure 5.4 just the frame, other parts may be removed from the bicycle. Although it is impossible to lock all the parts, it is suggested to lock the major components if possible. Figure 5.5 • Use a lock that is long enough to lock the frame and both wheels if possible. Some models with quick-release front wheels allow the front wheel to be placed beside the frame so a smaller lock can be used to lock all 3 components. • Be aware that a quick-release seat post can be stolen. It is recommended to remove the seat post and saddle and carry it with you if you believe that this is a risk. Figure 5.5 Schwinn Folding Bicycle Manual.indb 36 7/1/14 3:59 PM...

  • Page 38: Maintenance

    Correct routine maintenance of your new bike will ensure: should be taken out and re-greased. This will prevent accelerated bearing deterioration. • Smooth running • If paint has become scratched or chipped to the metal, use • Longer lasting components touch up paint to prevent rust. Clear nail polish can also be • Safer riding used as a preventative measure. • Lower running costs • Regularly clean and lubricate all moving parts, tighten components and make adjustments as required. Schwinn Folding Bicycle Manual.indb 37 7/1/14 3:59 PM...

  • Page 39: Lubrication Schedule

    Brake cables Lithium based grease Remove cable from casing. Grease entire length. Wipe off excess lubrication from other surfaces. Brake lever and caliper pivot points Light oil Two to three drops from oil can Shifting cables Thin layer of grease Clean and grease Yearly Bottom bracket Lithium based grease Disassemble Pedals Lithium based grease Disassemble Wheel bearings Lithium based grease Disassemble Headset Lithium based grease Disassemble Seat stem Lithium based grease Disassemble Pedals: that can be disassembled See bicycle mechanic for maintenance. Note: The frequency of maintenance should increase with use in wet or dusty conditions. Do not over lubricate. Remove excess lubricant to prevent dirt build up. Never use a degreaser to lubricate your chains (WD-40™). Schwinn Folding Bicycle Manual.indb 38 7/1/14 3:59 PM...

  • Page 40: Parts Maintenance

    Bead Seating Check for broken or loose spokes. See bicycle mechanic for repair. Tread Inspect for signs of excessive wear, flat spots or Replace tire. cuts and damage. Valves Check that valve caps are fitted and free of dirt. Clean dirt from the valve. Wheels Frequency: Inspect and maintain at least each use. Inspect Action Maintenance Rims Inspect for dirt and grease. Use a clean rag or wash with soapy water, rinse, and air dry. Wheels Check the wheels are securely fastened to the Adjust if necessary and tighten axle nuts. bicycle and axle nuts are tight. Spin wheel and check rotation / alignment is See bicycle mechanic for repair. true. Spokes Check for broken or loose spokes. See bicycle mechanic for repair. Hub Bearings Lift each wheel and see if there is movement side See bicycle mechanic for repair. to side. Schwinn Folding Bicycle Manual.indb 39 7/1/14 3:59 PM...
  • Page 41 Drivetrain (pedals, chains, chainwheel, crank set, freewheel) Frequency: as noted Inspect Action Maintenance Pedals Every month, check each pedal is securely set and tighten into If necessary, re-set and tighten. the crank arm. Before each ride, check each front and rear pedal reflectors are Clean or replace. clean and in place. Pedal Bearings Every ride, check the pedal bearings are properly adjusted. See bicycle mechanic for repair. Move the pedal up and down, left and right. If looseness or roughness is detected adjustment, lubrication or replacement is required. Chains Every week, check the chain is clean, properly lubricated, Lubricate if necessary. Replace if rusted, rust-free, and is not stretched, broken, or has stiff links. stretched, or broken. Crank Set Every month, check the crank set (crank arms, chain rings, See bicycle mechanic for repair. and bottom bracket axle and bearings) is correctly adjusted and tight. Schwinn Folding Bicycle Manual.indb 40 7/1/14 3:59 PM...
  • Page 42 Maintenance 6 Brakes Frequency: Inspect and maintain before each use Inspect Action Maintenance Levers Check the levers are securely fastened to the handlebar. Position the levers to fit the rider’s grip and screw tight to handlebar. Pads Check pad position, gap and pressure. See Section 4: Adjusting the Brakes Cables Check the outer casing for kinks, stretched coils and damage. Replace cable. Check cables for kinks, rust, broken strands or frayed ends. Check the outer casing for kinks, stretched coils and damage. Check the housing is seated properly into each cable stop of It is recommended that the cables and the bicycle. housing be replaced every riding season. Schwinn Folding Bicycle Manual.indb 41 7/1/14 3:59 PM...

  • Page 43: Hub Bearings

    • Over-inflation or inflating the tube too quickly may result in the tire blowing off the rim and damaging the bicycle or ❷ To adjust, remove wheel from bicycle and loosen the locknut causing injury to the rider. Always use a hand pump to on one side of the hub while holding the bearing cone on inflate the tube. Do not use a gas station service pump to the same side with a cone wrench. inflate the tube. ❸ Rotate the adjusting cone as needed to eliminate free play. Follow these steps to inflate a tire: ❹ Re-tighten the locknut while holding the adjusting cone in ❶ Remove the valve cap and add air. position. ❺ Re-check that the wheel can turn freely without excessive ❷ Check the tire is evenly seated on the rim, both sides. side play. ❸ Spin the wheel and check for high and low areas. ❹ Complete inflation to the recommended psi found on the sidewall of the tire. ❺ Be sure the tire is evenly seated on the rim, both sides. If not, release some air and repeat steps three through six. ❻ Check for dirt in the valve cap or stem. Clean dirt from cap or stem. ❼ Securely replace the valve cap on the stem. Schwinn Folding Bicycle Manual.indb 42 7/1/14 3:59 PM...

  • Page 44: Repairing A Flat Tire

    RePAIRING A fLAt tIRe WARNING! ❿ Start at the valve stem and install the first bead onto the rim. Repeat for the second bead. An unseated tire can rupture unexpectedly and cause serious injury or death. Be sure the tire is properly seated when ⓫ Slowly inflate the tire, checking the tire is seated properly inflating the tube. and not pinched as the tire is inflated. Follow these steps to fix a flat tire: ⓬ Inflate to recommended pressure (see tire sidewall). ❶ Match tube size and tire size (see tire sidewall for size). ❷ Remove the wheel from the bicycle. Deflate tire completely. ❸ Squeeze the tire beads into the center of the rim. ❹ Opposite the valve, use a bicycle tire lever to pry the tire bead up and out of the rim. Repeat around the wheel until one bead is off the rim. ❺ Remove tube. Release second tire bead. ❻ Remove tire. ❼ Carefully inspect inside of the rim and tire for the cause of the flat. ❽ Inflate the tube ¼ full and place inside tire. ❾ Insert the valve stem through valve stem hole in rim. Schwinn Folding Bicycle Manual.indb 43 7/1/14 3:59 PM...

  • Page 45: Troubleshooting Guide

    • Adjust bearings/axle nut • Loose bottom bracket axle/bearings • Adjust bottom bracket • Bent bottom bracket or pedal axle • Replace bottom bracket axle or pedals • Loose crankset • Tighten crank bolts Grinding noise when • Pedal bearings too tight • Adjust bearings pedaling • Bottom bracket bearings too tight • Adjust bearings • Chain fouling derailleurs • Adjust chain line • Derailleur jockey wheels dirty/binding • Clean and lubricate jockey wheels Schwinn Folding Bicycle Manual.indb 44 7/1/14 3:59 PM...
  • Page 46 • Brakes out of adjustment • Center brakes and/or adjust brake pads toe-in • Fork loose in head tube • Tighten headset Wobbling wheel • Axle broken • Replace axle • Wheel out of true • True wheel • Hub comes loose • Adjust hub bearings • Headset binding • Adjust headset • Hub bearings collapsed • Replace bearings • Quick-release mechanism loose • Adjust quick-release mechanism Schwinn Folding Bicycle Manual.indb 45 7/1/14 3:59 PM...
  • Page 47 • Adjust/tighten headset • Front forks or frame bent • Take bike to a bike shop for possible frame realignment Frequent • Inner tube old or faulty • Replace inner tube punctures • Tire tread/casing worn • Replace tire • Tire unsuited to rim • Replace with correct tire • Tire not checked after previous puncture • Remove sharp object embedded in tire • Tire pressure too low • Correct tire pressure • Spoke protruding into rim • File down spoke Schwinn Folding Bicycle Manual.indb 46 7/1/14 3:59 PM...

  • Page 48: Warranty

    NOTICE: Bicycle specifications subject to change without notice. Schwinn Folding Bicycle Manual.indb 47 7/1/14 3:59 PM...

  • Page 49: Purchase Record

    Place of Purchase: Model & Brand Information: Wheel Size: Color: Model Number: Model Number: Date Code: Serial number note: The serial number can be on the bottom of the frame underneath the crank shaft. Schwinn Folding Bicycle Manual.indb 48 7/1/14 3:59 PM...
  • Page 50 4902 Hammersley Road Madison, WI 53711 Service: 1-800-626-2811 www.pacific-cycle.com OMSCFLD ©2014...
