Icom IC-910H Service Manual page 52

[MAIN UNIT]
REF ORDER
NO. NO.
R1679 7030003680 S.RESISTOR
R1680 7030003560 S.RESISTOR
R1681 7030003680 S.RESISTOR
R1682 7030003680 S.RESISTOR
R1685 7030003680 S.RESISTOR
R1686 7030003320 S.RESISTOR
R1688 7030003320 S.RESISTOR
R1689 7030003680 S.RESISTOR
R1690 7030003600 S.RESISTOR
R1691 7030003600 S.RESISTOR
R1692 7030003680 S.RESISTOR
R1693 7030003680 S.RESISTOR
R1701 7030003720 S.RESISTOR
R1702 7030003560 S.RESISTOR
R1703 7030003520 S.RESISTOR
R1704 7030003590 S.RESISTOR
R1705 7030003600 S.RESISTOR
R1706 7030003560 S.RESISTOR
R1707 7030003570 S.RESISTOR
R1708 7030003520 S.RESISTOR
R1709 7030003560 S.RESISTOR
R1710 7030003640 S.RESISTOR
R1711 7030003440 S.RESISTOR
R1712 7030003640 S.RESISTOR
R1713 7030003720 S.RESISTOR
R1714 7030003680 S.RESISTOR
R1715 7030003290 S.RESISTOR
R1716 7030003720 S.RESISTOR
R1717 7030003720 S.RESISTOR
R1718 7030003540 S.RESISTOR
R1719 7030003560 S.RESISTOR
R1720 7030003600 S.RESISTOR
R1721 7030003680 S.RESISTOR
R1722 7030003560 S.RESISTOR
R1723 7030003600 S.RESISTOR
R1724 7030003680 S.RESISTOR
R1725 7030003540 S.RESISTOR
R1726 7030003540 S.RESISTOR
R1727 7030003680 S.RESISTOR
R1728 7030003670 S.RESISTOR
R1729 7030003360 S.RESISTOR
R1730 7030003440 S.RESISTOR
R1731 7030003520 S.RESISTOR
R1732 7030003560 S.RESISTOR
R1733 7030003560 S.RESISTOR
R1734 7030003640 S.RESISTOR
R1735 7030003560 S.RESISTOR
R1771 7030003400 S.RESISTOR
R1772 7030003400 S.RESISTOR
R1773 7030003400 S.RESISTOR
R1774 7030003400 S.RESISTOR
R1775 7030003400 S.RESISTOR
R1776 7030003400 S.RESISTOR
R1781 7030003400 S.RESISTOR
R1782 7030003400 S.RESISTOR
R1783 7030003400 S.RESISTOR
R1784 7030003400 S.RESISTOR
R1785 7030003400 S.RESISTOR
R1786 7030003400 S.RESISTOR
R1801 7030003640 S.RESISTOR
R1802 7030003440 S.RESISTOR
R1803 7030003560 S.RESISTOR
R1804 7030003670 S.RESISTOR
R1805 7030003670 S.RESISTOR
R1806 7030003560 S.RESISTOR
R1807 7030003700 S.RESISTOR
R1808 7030003680 S.RESISTOR
R1809 7030003700 S.RESISTOR
R1810 7030003520 S.RESISTOR
R1811 7030003430 S.RESISTOR
R1812 7030003520 S.RESISTOR
R1813 7030003430 S.RESISTOR
R1814 7030003440 S.RESISTOR
R1815 7030003460 S.RESISTOR
R1816 7030003580 S.RESISTOR
R1817 7030003580 S.RESISTOR
R1818 7030003640 S.RESISTOR
R1821 7030003640 S.RESISTOR
R1822 7030003640 S.RESISTOR
R1823 7030003640 S.RESISTOR
R1824 7030003560 S.RESISTOR
R1825 7030003560 S.RESISTOR
DESCRIPTION
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 560 V (56 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
From The N3UJJ.COM Document Library From The N3UJJ.COM Document Library
[MAIN UNIT]
REF ORDER
NO. NO.
R1826 7030003510 S.RESISTOR
R1829 7030003640 S.RESISTOR
R1830 7030003680 S.RESISTOR
R1831 7030003640 S.RESISTOR
R1833 7030003640 S.RESISTOR
R1834 7030003320 S.RESISTOR
R1835 7030003320 S.RESISTOR
R1838 7030003430 S.RESISTOR
R1839 7030003430 S.RESISTOR
R1840 7030003320 S.RESISTOR
R1841 7030003640 S.RESISTOR
R1842 7030003600 S.RESISTOR
R1843 7030003560 S.RESISTOR
R1844 7030009340 S.RESISTOR
R1845 7030003790 S.RESISTOR
R1846 7030003720 S.RESISTOR
R1847 7030003550 S.RESISTOR
R1848 7030003440 S.RESISTOR
R1849 7030003550 S.RESISTOR
R1850 7030003320 S.RESISTOR
R1851 7030003640 S.RESISTOR
R1852 7030003600 S.RESISTOR
R1853 7030003560 S.RESISTOR
R1854 7030009340 S.RESISTOR
R1855 7030003790 S.RESISTOR
R1856 7030003720 S.RESISTOR
R1857 7030003550 S.RESISTOR
R1858 7030003440 S.RESISTOR
R1859 7030003550 S.RESISTOR
R1861 7030003700 S.RESISTOR
R1862 7510001300 S.THERMISTOR
R1864 7030003360 S.RESISTOR
R1865 7030003440 S.RESISTOR
R1866 7030003360 S.RESISTOR
R1867 7030004040 S.RESISTOR
R1869 7030004040 S.RESISTOR
R1871 7030003680 S.RESISTOR
R1872 7030003680 S.RESISTOR
R1874 7030003680 S.RESISTOR
R1875 7030003640 S.RESISTOR
R1876 7030003700 S.RESISTOR
R1879 7030003740 S.RESISTOR
R1880 7030003760 S.RESISTOR
R1881 7030003720 S.RESISTOR
R1882 7030003400 S.RESISTOR
R1883 7030003740 S.RESISTOR
R1884 7030003760 S.RESISTOR
R1885 7030003720 S.RESISTOR
R1886 7030003400 S.RESISTOR
R1887 7030003740 S.RESISTOR
R1888 7030003640 S.RESISTOR
R1889 7030003740 S.RESISTOR
R1890 7030003640 S.RESISTOR
R1891 7030003520 S.RESISTOR
R1892 7030003520 S.RESISTOR
R1893 7030003560 S.RESISTOR
R1894 7030003560 S.RESISTOR
R1895 7030003500 S.RESISTOR
R1896 7030003520 S.RESISTOR
R1897 7030003360 S.RESISTOR
R1898 7030003360 S.RESISTOR
C1 4030006900 S.CERAMIC
C2 4030006900 S.CERAMIC
C3 4030006900 S.CERAMIC
C4 4030006900 S.CERAMIC
C5 4030006900 S.CERAMIC
C6 4030006880 S.CERAMIC
C7 4030011810 S.CERAMIC
C8 4030006900 S.CERAMIC
C10 4030006900 S.CERAMIC
C21 4550006390 S.TANTALUM
C22 4030012610 S.CERAMIC
C51 4030006900 S.CERAMIC
C52 4030006900 S.CERAMIC
C53 4030006900 S.CERAMIC
C54 4030006950 S.CERAMIC
C55 4030006900 S.CERAMIC
C56 4030006880 S.CERAMIC
C57 4030011600 S.CERAMIC
C58 4030006900 S.CERAMIC
6 - 13
DESCRIPTION
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 275V (2.7 MΩ)
ERJ3GEYJ 824 V (820 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 275V (2.7 MΩ)
ERJ3GEYJ 824 V (820 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
NTCCM1608 4LH 223KC
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 4R7 V (4.7 Ω)
ERJ3GEYJ 4R7 V (4.7 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 221 V (220 Ω)
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1A 224K-T-N
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
TEMSVA 1C 335M-8L
C2012 JB 1C 474K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 CH 1H 040C-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1E 103K-T-A
S.=Surface mount
