- Page 1 OWNER’S MANUAL WINSLOW GAZEBO Caution: Carefully Read Instructions and Procedures for Safe Operation KSN: 0-06298288-9 UPC Code: 846822013183 Date of Purchase: _____/ _____/ _____...
- Page 2 Warning: 1. When assembling and using this product, basic safety precautions should always be followed to reduce the risk of personal injury and damage to equipment. Please read all instructions before assembly and use. 2. Some parts may contain sharp edges, wear protective gloves if necessary. At least four or more people are recommended for safe assembly.
- Page 3 WINSLOW GAZEBO PARTS LIST PA RT DESCRIPTION Screen 1 Screen 2 Pole Big Top Long Pole Connector Big Top Long Pole Big Top Pole Short Big Top Connector Small Top Pole Small Top Connector Corner Shelf Decorative Finial Hook Canopy...
- Page 4 WINSLOW GAZEBO ASSEMBLY INSTRUCTION WINSLOW GAZEBO HARDWARE PACK 1 Description Qty. Part M6×32 Bolt 28 pcs M6 Washer 44 pcs M6 Nut 16 pcs M6 Wrench 2 pcs Step1 Fig.2 Fig.3 Fig.1 Fig.1 CC BB A1/B1 Fig.2 Fig.3 Fig.1: Connect Screen 1(A1) to Screen 2(B1) by M6 Washer (CC) and M6x32 Bolt (BB).
- Page 5 WINSLOW GAZEBO ASSEMBLY INSTRUCTION WINSLOW GAZEBO HARDWARE PACK 2 Description Qty. Part M6×20 Bolt 4 pcs M6 Washer 4 pcs Fig.8 Step2 Fig.9 Fig.6 Fig.5 Fig.4 Fig.7 Fig.5 Fig.4 Fig.6 Fig.4: Insert Big Top Long Pole Connector (D) into assembled screens.(A1/B1) Fig.5: Insert Big Top Long Pole (E) into Big Top Long Pole Connector (D).
- Page 6 WINSLOW GAZEBO ASSEMBLY INSTRUCTION WINSLOW GAZEBO HARDWARE PACK 3 6×180 Stake 16pcs Plastic Tie 40pcs Fig.10 Step3 Fig.11 Fig.12 Fig.13 Fig.11 Fig.10 Fig.12 C(A1/B1) Fig.10:Place the big canopy O onto the big Fig.13 top frame but do not layout it completely;...
- Page 7 WINSLOW GAZEBO ASSEMBLY INSTRUCTION It is advised that the Canopy should be removed in the winter for best protection and length of use. Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once these protective coatings are scratched.
- Page 8 Please refer to part numbers when reordering For questions or comments about product: Email: kmart@sunjoygroup.com or Call toll-free: 866-578-6569 Made in / Hecho en CHINA for Kmart Corporation, Hoffman Estates , IL 60179 See our extensive assortment of outdoor living products See our extensive assortment of outdoor living products on-line at www.sears.com and www.kmart.com on-line at www.sears.com and www.kmart.com...
