S T E P
O P E R A T I O N
Press [2] and then [TIME
DATE] button on Unit 2.
7
Press [3] and then [M+]
button on Unit 2.
8
Press [TEL] button on
Unit 2.
9
Press [ON] button on Unit
1.
10
Press [TEL] button on
Unit 1.
11
Press [FUNC] button on
both Unit 1 and Unit 2.
12
Press [FUNC] button on
both Unit 1 and Unit 2.
13
Press [4] button to select
14
"4 DATA COMM"on both
Unit 1 and Unit 2.
Press [2] button to select
"2 RECEIVE"on Unit 2.
15
Press [1] button to select
"1 SEND" on Unit 1.
16
Press [3] button to select
"3 ALL DATA" on Unit 1.
17
Press [SHIFT] and then
[SET] button on Unit 1.
18
19
DISPLAY
1901/ 2/
M
SUN
1901/ 2/ 3
TEL mode display
Mode display before power off
TEL mode display
X ITEM EDIT
X ITEM DELETE
X ITEM COPY
4 SOUND
X TO SECRET
2 ALL DELETE
3 LABEL EDIT
4 DATA COMM
1 SEND
2 RECEIVE
3 SET UP PAR.
RECEIVE
DATA
TO STOP
PRESS(ESC)
1 ONE ITEM
1 ONE ITEM
2 MODE DATA
2 MODE DATA
3 ALL DATA
3 ALL DATA
-SEND-
-SEND-
SEND ALL DATA ?
SET / ESC
Unit 1 : SENDING
Unit 2 : RECEIVE OK
Within a few minutes, both Units
display become TEL mode.
Confirm the data displayed on
Unit 2.
— 11 —
N O T E
Set SET UP PAR to PARITY N,
BIT LENGTH 7 and BPS 9600 on
Unit1.
Data transmission completed
