Resolution
Vertical Frequency
(O) Vertical Period
(P) Vertical Pulse Width
(Q) Vertical Back Porch
(R) Vertical Active Area
(S) Vertical Front Porch
Resolution
Vertical Frequency
(O) Vertical Period
(P) Vertical Pulse Width
(Q) Vertical Back Porch
(R) Vertical Active Area
(S) Vertical Front Porch
VGA Compatible
640~ 350 720~ 400
70.080Hz 70.080Hz 59.940Hz
14.268msec 14.268msec 16.683msec
0.064msec 0.064msec
1.716msec 0.890msec
11.504msec 13.156msec 15.762msec
0.985msec 0.159msec
VESA
VESA
800~ 600
640~ 480
at 56Hz
at 72Hz
640~ 480 800~ 600
72.809Hz
56.250Hz
13.735msec 17.778msec
0.079msec 0.057msec
0.740msec 0.626msec
12.678msec 17.067msec
0.238msec 0.028msec
XGA-2 Compatible
640~ 480 720~ 350 720~ 400
87.850Hz 87.850Hz
11.383msec 11.383msec
0.064msec 0.051msec 0.051msec
0.793msec 1.496msec 0.862msec
8.873msec 10.141msec
0.064msec 0.963msec 0.329msec
VESA
VESA
800~ 600 800~ 600
at 72Hz
at 60Hz
800~ 600 800~ 600
60.317Hz 72.187Hz
16.579msec 13.853msec
0.106msec 0.125msec
0.607msec 0.478msec
15.840msec 12.480msec
0.026msec 0.770msec
Mac U , Quadra,
or LC Compatible
640~ 480
640~ 480
75.000Hz
66.667Hz
13.333msec
15.000msec
0.051msec 0.090msec
0.813msec
1.110msec
12.190msec
13.710msec
0.279msec
0.090msec
MAC U 8514/A & XGA
& Interlaced
Quadra Compartible
832~ 624 1024~ 768
74.550Hz 86.960Hz
13.414msec 11.499msec
0.060msec 0.112msec
0.784msec 0.577/0.563msec
12.549msec 10.824msec
0.020msec
0.000/0.014msec
51
VESA
1024~ 768
at 60Hz
1024~ 768
60.000Hz
16.667msec
0.124msec
0.600msec
15.880msec
0.062msec
52
