OFF_HOUR: Turn off time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): Off timer isn't set.
OFF_MIN: Turn off time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59 (=3Bh)
'3'-'C'(33h, 43h): Off timer isn't set.
INPUT: Timer input
'0'-'0'(30h, 30h): RGB1(DVI-D)
'0'-'1'(30h, 31h): RGB2(D-SUB)
'0'-'2'(30h, 32h): RGB3(BNC)
'0'-'3'(30h, 33h): DVD/HD
'0'-'4'(30h, 34h): VIDEO
'0'-'5'(30h, 35h): VIDEO(S)
'0'-'7'(30h, 37h): It is o
WD: Week setting
bit 0: Monday
bit 1: Tuesday
bit 2: Wednesday
bit 3: Thursday
bit 4: Friday
bit 5: Saturday
bit 6: Sunday
EX.
'0'-'1'(30h, 31h): Monday
'0'-'4'(30h, 34h): Wednesday
'0'-'F'(30h, 46h): Monday, Tuesday, Wednesday and Thursday
'7'-'F'(37h, 46h): Monday to Sunday
FL: Option
bit 0: Everyday
bit 1: Every week
bit 2: Schedule Disable/Enable
* When bit0 and bit1 are '1', it behaves as Everyday.
EX.
FL setting
'0'-'0'(30h, 30h)
'0'-'1'(30h, 31h)
'0'-'2'(30h, 32h)
'0'-'3'(30h, 33h)
'0'-'4'(30h, 34h)
'0'-'5'(30h, 35h)
'0'-'6'(30h, 36h)
'0'-'7'(30h, 37h)
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.5 "Check code" for a BCC calculation.
Delimiter
CR (0Dh): End of packet
perates by last memory input
Schedule Everyweek
O
O
O
O
O O
O O
(25/38)
Everyday Schedule behavior
Schedule Disable
O Schedule Disable
Schedule Disable
O Schedule Disable
Once *Follow WD (Week setting)
O Everyday
Everyweek *Follow WD (Week setting)
O Everyday
