10.2 Schedule Write
This command is used in order to write the setting of the Schedule.
1) The controller requests the monitor to write Schedule
Header
SOH-'0'-'A'-'0'-'A'-'1'-'6'
Header
SOH (01h): Start Of Header
'0' (30h): Reserved
'A' (41h): Monitor ID
LCD3210 must be ASCII 'A' (41h).
'0' (30h): Message sender is the controller
'A' (41h): Message type is "Command"
'1'-'6'(31h, 36h): Message length.
Message
STX (02h): Start of Message
'C'-'2'-'1'-'4' (43h, 32h, 31h, 34h): Schedule writes command
PG-ON HOURS-ON MIN-OFF HOURS-OFF Min-INPUT-WD-FL: Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
'0'-'6'(30h, 36h): Program No.7
ON_HOUR: Turn on time (hour)
'0'-'0'(30h, 30h): 00
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): ON timer isn't set.
ON_MIN: Turn on time (minute)
'0'-'0'(30h, 30h): 0
'3'-'B'(33h, 42h): 59
'3'-'C'(33h, 43h): On timer isn't set.
OFF_HOUR: Turn off time (hour)
'0'-'0'(30h, 30h): 00
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): Off timer isn't set.
OFF_MIN: Turn off time (minute)
'0'-'0'(30h, 30h):0min
'3'-'B'(33h, 42h):59 (=3Bh)
'3'-'C'(33h, 43h): Off timer isn't set.
INPUT: Timer input
'0'-'0'(30h, 30h): RGB1(DVI-D)
'0'-'1'(30h, 31h): RGB2(D-SUB)
'0'-'2'(30h, 32h): RGB3(BNC)
'0'-'3'(30h, 33h): DVD/HD
'0'-'4'(30h, 34h): VIDEO
'0'-'5'(30h, 35h): VIDEO(S)
'0'-'7'(30h, 37h): It is o
WD: Week setting
bit 0: Monday
bit 1: Tuesday
bit 2: Wednesday
bit 3: Thursday
bit 4: Friday
bit 5: Saturday
bit 6: Sunday
STX-'C'-'2'-'1'-'4'-PG-ON HOURS-ON MIN-OFF
HOURS-OFF Min-INPUT-WD-FL-ETX
|
|
|
|
|
.
Message
perates by last memory input
(26/38)
Check code
Delimiter
BCC
CR
