Installation

Wiring Diagram

IBM XGA/SuperVGA/VGA or
Compatibles
IBM/MAC MultiCable
To D-SUB 15 Pin input
OUT
Document camera, VCR, Video copy stand
or Multimedia application
Macintosh or
Compatibles
IBM/MAC MultiCable
To D-SUB 15 Pin input
OUT OUT OUT
To VIDEO IN R, L, inputs
To EXTERNAL CONTROL
(D-SUB 15 Pin input)
XP29 Plus/XM29 Plus
To R,G,B,H, V inputs (BNC)
PROCEED
Multisync
XP29Plus/XM29Plus
NOTE: The two RGB1 D-Sub 15-pin connectors here can be used to
either input or output video to or from a PC or Macintosh computer.
Either connector can be used for input or output, however they cannot
both be used for input simultaneously. It can damage your computer.
