- Page 1 Integrated High Speed Dome Camera Indoor Installation Guide Version 3.2 00P6H7010ZSEC2...
- Page 2 Installation Guide Preface The information given in this manual was current when published. The company reserves the right to revise and improve its products. All specifications are subject to change without notice. Notice This manual provides the installation information for the indoor integrated high speed dome.
- Page 3 Installation Guide This symbol on the product or on its packaging indicates that this product shall not be treated as household waste in accordance with Directive 2002/96/EC. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
-
Page 4: Warnings And Cautions
Installation Guide Warnings and Cautions • Handle the camera carefully Do not abuse the camera. Avoid striking, shaking, etc. The camera could be damaged by improper handing or storage. • Installing electricity wiring carefully Ask qualified personnel of electrical wiring for the installation. Please note that input electricity to the unit is at tolerance of DC 12V/AC 24V ±... - Page 5 Installation Guide • Never face the camera towards the sun Do not aim the camera at bright objects. Whether the camera is in use or not, never aim it at the sun or other extremely bright objects. Otherwise, the camera may be smeared or damaged.
-
Page 6: Table Of Contents
Installation Guide Table of Contents Introduction ..........................7 Standard Package Content....................8 Dome Setups and Cable Connection ................. 10 Dome Camera Setups....................10 3.1.1 Switch/Connector Definition................. 10 3.1.2 Communication Switch Setting ..............12 3.1.2.1 Analog Dome Camera..............12 3.1.2.2 IP Dome Camera ............... 13 3.1.3 ID Setting ..................... - Page 7 Installation Guide 4.5.1 Corner Standard Mounting Plate/Corner Plate Mini........46 4.5.2 Corner Thin/Wide Box Mounting..............48 Pole Mount ......................... 50 4.6.1 Pole Thin/Wide Direct Mounting ..............50 4.6.2 Pole Thin/Wide Box Mounting ..............52 System Expansion ....................... 54 Connecting with Connector Box ................. 54 Data Formats Transforming ..................
-
Page 8: Introduction
In addition, the Dome Camera supports one cabling for easy installation. Large set of built-in protocols, including DynaColor, Pelco, VCL, Philips, AD-422 (Manchester), etc., provide connectivity to other suppliers’ surveillance systems. General Operation Requirements: A minimum of one control device is required for operation, such as a control keyboard, a DVR or a PC. -
Page 9: Standard Package Content
Installation Guide Standard Package Content Before proceeding, please check the box contains the items listed here. If any item is missing or has defects, DO NOT install or operate the product and contact your dealer for assistance. Analog Dome Camera Package Hard Ceiling Mount and Fixing Plate Dome Body... - Page 10 Installation Guide IP Dome Camera Package Hard Ceiling Mount and Fixing Plate Dome Body Decoration Ring 5.4” Optical Cover Data Cable for Power Quick Guide Supply, Video and Audio (AC 24V) CD: Operation Manuals...
-
Page 11: Dome Setups And Cable Connection
Installation Guide Dome Setups and Cable Connection Before installing or connecting the Dome Camera, please refer to this section and complete preparations for dome setups and various switch settings. There will be a PE cloth sheet covered inside the dome cover and a lens cap on the lens for shipping protection. - Page 12 Installation Guide G/V/T/L/M/R Models Reserved Communication Switch ID Switch Camera Control Protocol Switch RJ-45 Connector (for IP Dome Camera only) 22-Pin Connector ISP Connector (for FW upgrade) S1/S2 Models Analog Camera Control Protocol Switch None Communication Switch Communication Switch None RJ-45 Connector 22-Pin Connector 22-Pin Connector...
-
Page 13: Communication Switch Setting
Installation Guide 3.1.2 Communication Switch Setting The table below shows the function of each switch within the Communication Switch for the analog and IP Dome Cameras. 3.1.2.1 Analog Dome Camera Communication Switch SW 1 RS-485 Setting SW 2 Termination SW 3 Line Lock SW 4 System Initialization... -
Page 14: Ip Dome Camera
Installation Guide 3.1.2.2 IP Dome Camera The IP Dome Camera’s communication switches are specified in the table below. Each switch’s default setting is shown as the figure below. DO NOT change the default setting, or some functions may not work properly. Communication Switch SW 1 Audio Setting... -
Page 15: Analog Dome Camera
Installation Guide 3.1.3.2 IP Dome Camera Set the Dome Camera’s ID to “001” as shown below. Please set every IP Dome Camera’s ID to “001” even you install multiple IP Dome Cameras. Centesimal Digit Decimal Digit Single Digit 3.1.4 Camera Control Protocol Setting Define the protocol you are going to use basing on the devices of your surveillance system. -
Page 16: Cable Definition And Requirements
Installation Guide Select protocol: Pelco D, with switch no. 01 and baud rate 2400, for instance, the protocol switch should be set as shown below. Decimal Digit Single Digit NOTE: The number “0” should locate upwards as shown in the diagram above for correct switch definition. -
Page 17: 22-Pin Data Cable
Installation Guide dome. NOTE: Ensure power supply corresponds with the dome’s power requirement, or product impairment will occur. If any mistake happens, please contact with a qualified maintenance engineer. 3.2.2 22-Pin Data Cable The analog and IP Dome Cameras’ Data Cables are illustrated as follows. 3.2.2.1 Analog Dome Camera The analog Dome Camera’s Data Cables are illustrated as shown below. -
Page 18: Ip Dome Camera
Installation Guide 3.2.2.2 IP Dome Camera The IP Dome Camera’s Data Cables are illustrated as shown below. AC 24V Data Cable DC 12V Data Cable 3.2.3 22-Pin Connector Definition With the 22-pin connector, installers can simply connect the power, video and RS-485 cables to the Dome Camera at once. -
Page 19: Analog Dome Camera
Installation Guide 3.2.3.1 Analog Dome Camera The analog Dome Camera’s 22-pin connector definition is listed as below. Definition Cable Definition Cable AC 24-1/DC (＋) 20AWG/18AWG ALM-1 ALM NC ALM-3 AC 24-2/DC (－) 20AWG/18AWG ALM-2 ALM NO ALM-4 20AWG/18AWG ALM-5 ALM COM ALM-6 ALM-7 ALM-8... -
Page 20: Rs-485 Connector Definition (Analog)
Installation Guide 3.2.4 RS-485 Connector Definition (Analog) RS-485 is the interface that communicates the Dome Camera and its control device. Please connect the control keyboard to the speed dome through the terminal block. The recommended cables for RS-485 communication are CAT 5 cables;... -
Page 21: Ethernet Cable Connection
Installation Guide Insert the terminal into the pin holes connector housing, with hook outward, as indicated in the figure. To unlock the terminal, press the hook, as indicated in the figure, with a proper tool and pull it out gently. Connect the 22-pin connector to the Dome Camera. -
Page 22: Dome Installation
Installation Guide Dome Installation Basing on user’s installation environments, the Dome Camera can be installed on ceiling, on wall or on pole. In the following sections, various indoor Dome Camera installation accessories, installation methods and installation procedures will be described in detail. In addition, the next section will provide the dome’s dimension for your reference before installation. - Page 23 Installation Guide Power Adapter 77H07-A1015 (Input: 100~115VAC/Output: 24VAC 36VA) 77H07-A2015 (Input: 220~230VAC/Output: 24VAC 36VA) NOTE: When wiring, make sure the G/Y wire (Ground) inserted into the mid-pin of the terminal block. Mounting Accessories Hard Ceiling Mount (Standard Equipment) For hard ceiling use. Height: 21.4mm ; Diameter of the three holes: 4.5mm ; Diameter of the bracket: 158mm T-Bar Ceiling Mount For in-ceiling Installation use.
- Page 24 Installation Guide Ceiling Panel For ceiling mounting. Zn platted; 610×305 mm (24×12 inches); Diameter: 155 mm (6.1 inches) Standard Pendent Mount White; 348×104×138.6 mm (13.7×4.1×5.5 inches); 1.5 kg (3.3 lbs); Diameter: 45 mm (1.8 inches). Supplied with rubber washer-8×1, pendent tube washer×1, spring washer-8×1 and M8*12 screw×1.
- Page 25 Installation Guide Straight Tube Iron; Height: 250/500 mm (9.8/19.7 inches); Diameter: 50 mm (2 inches) 1 kg (2.2 lbs) / 1.8 kg (4 lbs). Supplied with rubber washer-8×1, pendant tube washer×1, spring washer-8×1 and waterproof rubber×1, M8*12 screw×1. Indoor Mount Kit For mounting indoor Dome Camera onto a pendent mount/Straight Tube.
- Page 26 Installation Guide Corner Standard Mounting Plate 222(L)×204(W)×117(D) mm (8.7×8×4.6 inches); 2 kg (4.4 lbs). Supplied with washer-8×4, spring washer×4, M8*16 screw×4, M8 nut×4. Pole Thin Direct Mounting 232(L)×136(W)×60(D) mm (9.1×5.4×2.4 inches); Diameter: 112~140 mm (4.4~5.5 inches); 0.7 kg (1.6 lbs). Supplied with stainless steel straps×4, M8*16 screw×4, washer×4.
- Page 27 Installation Guide Corner Thin Box 300(L)×164(W)×222(D) mm (11.8×6.5×8.7 inches); 3 kg (6.7 lbs); Supplied with washer×4, M8*16 screw×4 and spring washer×4. Corner Wide Box 232(L)×234(W)×210(D) mm (9.1×9.2×8.3 inches); 2.7 kg (6 lbs); Supplied with washer×4, M8*16 screw×4 and spring washer×4. Pole Thin Box 291(L)×136(W)×242 (D) mm (11.5×5.4×9.5 inches);...
- Page 28 Installation Guide Pole Wide Box 270(L)×166(W)×155(D) mm (10.6×6.5×6.1 inches); 3.2 kg (7.1 lbs); Supplied with M8*16 screw×4, washer×4, spring washer×4, stainless steel straps×4. Wall Box Mounting 270(L)×166(W)×95(D) (10.6×6.5×3.7 inches); 2.2 kg (4.84 lbs); Supplied with M8*16 screw×4, washer×4, spring washer×4 Stainless Steel Straps For fixing Pole Direct Mounting/ Pole Box on the pole.
- Page 29 Installation Guide Other Application Accessories Repeater/Converter D77R1: RS-485/RS-422 Repeater D77R2: RS-232 between RS-485/RS-422 D77R3: Bi-phase to RS-485/RS-422 D77R1 D77R2 D77R3 Connector Box (Indoor Application) Recommended for wiring indoor dome alarm cables. White Color. 92×42 mm (3.7×1.7 inches); 0.13 kg (0.3 lbs); Supplied with cable×1, bracket×1 and M3*6 screw×2. Signal Distribution Unit Relay control codes to speed Dome Cameras.
-
Page 30: Ceiling Mount
Installation Guide Ceiling Mount Generally, there are three kinds of Dome Camera ceiling mounting methods: hard-ceiling, in-ceiling and mounting with Straight Tube. Refer to the following sections for more details. The following figures show how cables connect to the Dome Camera in different ways. - Page 31 Installation Guide • Ethernet Cable (IP Dome Camera) • Hard Ceiling Mount and Decoration Ring (supplied) • Fixing Plate (supplied) Tools Needed: • Tool for drilling • (+,–) Screw Driver Follow the steps to install the high speed Dome Camera for hard ceilings. STEP 1 Screw the Fixing Plate to your Dome Camera’s Body.
- Page 32 Installation Guide STEP 5 Fix the Mount to the holes on the hard ceiling with three screws, as marked in the figure. STEP 6 Thread the Data Cable and/or Ethernet cable through the center hole of the Mount and connect cable camera body.
-
Page 33: In-Ceiling Mounting
Installation Guide Completion 4.3.2 In-ceiling Mounting Here lists the items and tools needed to mount the Dome Camera into the ceilings. The supplied items are all in the Dome Camera package. Items Needed: • Dome Camera • Data Cable (supplied) •... - Page 34 Installation Guide Step 1: Disassemble wing (indicated in the diagram) from the T-Bar Ceiling Mount, and take out the supplied screw in the small bag. Step 2: Attach the separated wing to the dome, as shown in the figure. STEP 3 Place the Red Sticker on the ceiling plate, and cut the circle part out of the ceiling.
- Page 35 Installation Guide STEP 5 Rotate T-Bar wings of the hinge to fix the T-Bar at the edge of the ceiling opening. STEP 6 Tighten the screws, and the T-Bar wings will adhere to the ceiling. STEP 7 Put the 22-pin Data Cable and/or Ethernet cable down through the center hole of the T-bar and connect it to the...
-
Page 36: In-Ceiling Mounting With Ceiling Panel
Installation Guide STEP 9 Fix the Decoration Ring to the bracket and then place back the optical cover. NOTE: Make sure the optical cover is removed before carrying procedure. 4.3.3 In-ceiling Mounting with Ceiling Panel To mount the Dome Camera to a suspended ceiling with the T-Bar, the ceiling panel could be employed, as shown in the figure below. -
Page 37: Ceiling Mounting With Straight Tube
Installation Guide 4.3.4 Ceiling Mounting with Straight Tube The Straight Tube is available in different length: 25 cm and 30 cm. Items Needed: • Dome Camera • Data Cable (supplied) • Ethernet Cable (IP Dome Camera) • Straight Tube and other equipped items (optional accessory) •... - Page 38 Installation Guide 7) Fix the plate onto the Dome Camera’s back plate with the supplied small screw, marked in the figure. 8) Connect the cables to the Dome Camera. 9) Mount the Dome Camera to the Indoor Mount Kit. (Ensure the Dome Camera is fixed completely, and the thread holes on the Lock Screw Plate...
- Page 39 Installation Guide Ceiling Mounting: Straight Tube + Indoor Mount Kit...
-
Page 40: Wall Mount
Installation Guide Wall Mount The Dome Camera can be mounted on the wall with Compact Pendent Mount, Standard Pendent Mount and Wall Box. Please follow the installation instructions below for mounting the Dome Camera via different ways. 4.4.1 Compact Pendent Mount Items Needed: •... - Page 41 Installation Guide 4) Run the cable(s) through the Compact Pendent Mount with the Data Cable’s 22-pin cable coming out of the outlet. NOTE: Please block the cable entry hole with the supplied sponge to avoid insects entering the Pendant Mount. The sponge can be placed in two ways as shown in the illustrations below.
-
Page 42: Standard Pendent Mount
Installation Guide 4.4.2 Standard Pendent Mount Items Needed: • Dome Camera • Data Cable (supplied) • Ethernet Cable (IP Dome Camera) • Standard Pendent Mount and equipped items (optional accessory) • Indoor Mount Kit (optional accessory) • Waterproof Rubber (Indoor Mount Kit’s accessory) •... - Page 43 Installation Guide Wall Mounting: Standard Pendent Mount + Indoor Mount Kit...
-
Page 44: Wall Box Mounting
Installation Guide 4.4.3 Wall Box Mounting Items Needed: • Dome Camera • Data Cable (supplied) • Ethernet Cable (IP Dome Camera) • Standard/Compact Pendent Mount and equipped items (optional accessory) • Wall Box Mounting (optional accessory) • Indoor Mount Kit (optional accessory) •... -
Page 45: Wall Box Mounting
Installation Guide 7) Join the Dome Camera to the Indoor Mount Kit with the supplied screw and washers. Wall Box Mounting: Wall Box Mounting + Standard/Compact Pendent Mount + Indoor Mount Kit... -
Page 46: Corner Mount
Installation Guide Corner Mount 4.5.1 Corner Standard Mounting Plate/Corner Plate Mini Items Needed: • Dome Camera • Data Cable (supplied) • Ethernet Cable (IP Dome Camera) • Standard/Compact Pendent Mount and equipped items (optional accessory) • Corner Standard Mounting Plate/Corner Plate Mini (herein collectively called “Corner Mounting Plate”;... - Page 47 Installation Guide screws and washers. Then adjust the Waterproof Rubber to the joint. 6) Connect the cable(s) to the Dome Camera. 7) Join the Dome Camera to the Indoor Mount Kit with the supplied screw and washers. Corner Wall Mounting: Corner Standard/Mini Mounting Plate + Standard/Compact Pendent Mount + Indoor Mount Kit...
-
Page 48: Corner Thin/Wide Box Mounting
Installation Guide 4.5.2 Corner Thin/Wide Box Mounting Items Needed: • Dome Camera • Data Cable (supplied) • Ethernet Cable (IP Dome Camera) • Standard/Compact Pendent Mount and equipped items (optional accessory) • Corner Thin/Wide Box (optional accessory) • Indoor Mount Kit (optional accessory) •... - Page 49 Installation Guide 7) Join the Dome Camera to the Indoor Mount Kit with the supplied screw and washers. Corner Box Mounting: Corner Thin/Wide Box + Standard/Compact Pendent Mount + Indoor Mount Kit...
-
Page 50: Pole Mount
Installation Guide Pole Mount 4.6.1 Pole Thin/Wide Direct Mounting Items Needed: • Dome Camera • Data Cable (supplied) • Ethernet Cable (IP Dome Camera) • Standard/Compact Pendent Mount and equipped items (optional accessory) • Pole Thin/Wide Direct Mounting (optional accessory) •... - Page 51 Installation Guide 6) Connect the cable(s) to the Dome Camera. 7) Join the Dome Camera to the Indoor Mount Kit with the supplied screw and washers. Pole Direct Mounting: Pole Thin/Wide Direct Mounting + Standard/Compact Pendent Mount + Indoor Mount Kit...
-
Page 52: Pole Thin/Wide Box Mounting
Installation Guide 4.6.2 Pole Thin/Wide Box Mounting Items Needed: • Dome Camera • Data Cable (supplied) • Ethernet Cable (IP Dome Camera) • Standard/Compact Pendent Mount and equipped items (optional accessory) • Pole Thin/Wide Box Mounting (optional accessory) • Indoor Mount Kit (optional accessory) •... - Page 53 Installation Guide Pole Box Mounting: Pole Thin/Wide Box + Standard/Compact Pendent Mount + Indoor Mount Kit...
-
Page 54: System Expansion
Installation Guide System Expansion Connecting with Connector Box Ideally being used in indoor installation circumstances, a Connector Box provides easy wiring and well organized connection between alarms, cameras and other devices, for easy installation. To connect the connector box with other devices: •... -
Page 55: Data Formats Transforming
Installation Guide Data Formats Transforming To integrate other surveillance devices with the High Speed Dome Cameras or to extend the distance of communications, users could employ three kinds of repeater/converter, as shown below. With the advanced circuit design, these repeaters/converters offer 1KVrms isolation voltage and surge protection capability. -
Page 56: Signal Distribution Unit
Installation Guide Signal Distribution Unit The RS-485 Signal Distribution Unit (SDU) is designed to relay control codes to Speed Dome Cameras. It is capable of communicating with cameras up to 1.0 kilometers away. Additionally, the SDU can be installed in either “star” or “daisy chain”... -
Page 57: Coaxial Telemetry
Installation Guide Coaxial Telemetry The Coaxial Telemetry is a low-cost solution to long distance connection between Dome Cameras and controlling devices (e.g. DVR and keyboard). It simplifies the work of wiring by transmitting video and RS-485 control signals via one BNC line, so that to bring users economical benefits. The following is the coaxial telemetry application diagram. -
Page 58: System Integration
Installation Guide System Integration The Dome Camera is allowed to be integrated into other suppliers' surveillance systems with large set of built-in protocols. Refer to the following sections for more information. Using Pelco Keyboard The Speed Dome Camera can be controlled through a Pelco keyboard which built in with D protocol and P protocol. -
Page 59: Using Philips Allegiant Keyboard
Installation Guide Cable Definition (D Protocol Keyboard to PTZ Camera) T x+ T x - T x+ T x- Rx + For D Protoc ol Ke yb oa rd Fo r Sp eed Dom e Using Philips Allegiant Keyboard The Dome Cameras can be integrated into Philips Allegiant systems through D77R3 repeaters. -
Page 60: Appendix A: Technical Specification
Auto / Manual AGC control Back Light On / Off Compensation OPERATION DynaColor, Pelco D&P, VCL, Philips, AD-422, JVC, Kalatel, etc. Built-in Protocol English, French, German, Italian, Japanese, Polish, Portuguese, Multi-Language OSD Russian, Spanish, Turkish, Simplified Chinese, Traditional Chinese 360° endless Pan Travel -10°~100°... - Page 61 Installation Guide Items R Model G Model M Model V Model L Model T Model Cruise Privacy Mask On / Off (Pan and tilt speed proportional to zoom ratio) Proportional Pan & Tilt Resume after Power loss Zone Title Preset, Sequence, Auto pan, Cruise Home Function Mechanical / Digital / Mechanical / Off...
- Page 62 Auto / Manual AGC control On / Off Back Light Compensation OPERATION DynaColor, Pelco D&P, VCL, Philips, AD-422, JVC, Kalatel, etc. Built-in Protocol English, French, German, Italian, Japanese, Polish, Portuguese, Multi-Language OSD Russian, Spanish, Turkish, Simplified Chinese, Traditional Chinese 360° endless Pan Travel -10°...
- Page 63 Installation Guide Items S1 Model S2 Model On / Off (Pan and tilt speed proportional to zoom ratio) Proportional Pan & Tilt Resume after Power loss Zone Title Preset, Sequence, Auto pan, Cruise Home Function Mechanical / Digital / Off Auto Flip On / Off Digital Slow Shutter...
