NEC MultiSync MD304MC Specifications page 2

Achieve complete color and brightness uniformity.
By nature, LCD panels and CCFL backlights con-
tain uniformity errors, or mura, which are visible
as slightly brighter or darker areas on the screen.
To combat this inherent trait, each MultiSync
MD304MC display is individually characterized
during production using a fully automated system
that measures hundreds of points across the
screen at different gray levels. These measure-
ments are used to build a 3-D correction matrix
stored inside the display. This data is used to
compensate for the uniformity not only as a func-
tion of position on the screen but of gray level as
well. In turn, this technology, called ColorComp,
reduces the non-uniformity to virtually unnotice-
able levels and applies a digital correction to each
pixel on the screen to compensate for differences
in color and luminance.
The MD304MC's design allows you to adjust
the display to your exact ergonomic preferences.
In addition to tilt and swivel functionality, the
height adjusts up to 190mm, and the display
pivots between landscape to portrait orientations.
MultiSync is a registered trademark, and ColorComp, GammaComp,
and X-Light are trademarks of NEC Display Solutions. All other
brand or product names are trademarks or registered trademarks of
their respective holders. Product specifications subject to change.
©2008 NEC Display Solutions of America, Inc.
All rights reserved. 11/08 Ver. 2.
Model
Display
Viewable Size Image
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)
Response Time (typical)
Panel Bit Depth
Color Gamut*
Coverage
Size
Synchronization Range
Horizontal
Vertical
Video Bandwidth
Input Signal
Video
Sync
Inputs
Resolutions Supported (Analog/Digital)
Native Resolution
Additional Features
Touch-Capable
Voltage Rating
Power Consumption (typical)
On
Power Savings Mode
Dimensions (WxHxD)
Net (with stand)
Net (without stand)
Net Weight
(with stand)
(without stand)
VESA Hole Configuration
Specifications
Environmental Conditions
Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude
Safety Standards
Limited Warranty
* Color gamut size and coverage calculated as 2-D gamut area in CIE 1931 xy colorspace. Size is the total relative display gamut area
and includes any colors outside the reference gamut. Coverage is the relative display gamut area contained inside the reference gamut.
NTSC values provided for comparison purposes - modern broadcast video uses SMPTE-C, ITU-R BT, 709-5/sRGB or EBU primatries.
** AdobeRGB is a standard defined by Adobe Systems Incorporated.
*** 640 x 400 available with DIGITAL input only only
**** 30 Hz refresh rate available with ANALOG input only
***** Backlight usage limited to 20,000 hours at 200 cd/m
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, IL 60143
866-NEC-MORE
MultiSync MD304MC
29.8"
0.251mm
101
200 cd/m calibrated / 350 cd/m max
2 2
1000:1
178° Vert., 178° Hor. (89U/89D/89L/89R)@ CR>10
Rapid Response™ (6ms Gray-to-Gray; 12ms Black-to-Black)
12-bit internal LUTs, displays 16.7 million colors out of 68.5 billion
color palette and 256 shades of gray out of 4096
AdobeRGB** - 97.8% / sRGB - 100%
AdobeRGB - 108% / sRGB - 145.7%
24 - 93.8 KHz (Analog/Digital)
24 - 85 Hz
25.2 - 268.5 MHz (DualLink)
Analog RGB 0.7 Vp-p/75 Ohms
Separate sync: TTL Level (Positive/Negative)
Composite sync: TTL Level (Positive/Negative)
Composite sync on green: (0.3Vp-p negative 0.7Vp-p positive)
DVI-D (HDCP), DVI-I
640 x 400 @ 70-85 Hz***
1400 x 1050 @ 60-75 Hz
720 x 400 @ 70-85 Hz 1440 x 900 @ 60-85 Hz
640 x 480 @ 60-85 Hz 1600 x 1200 @ 60-75 Hz****
800 x 600 @ 56-85 Hz 1680 x 1050 @ 60-75 Hz****
832 x 624 @ 75 Hz 1920 x 1200 @ 60 Hz
1024 x 768 @ 60-85 Hz 1920 x 1440 @ 30-60Hz****
1152 x 864 @ 70-85 Hz 2560 x 1600 @ 30-60 Hz****
1152 x 870 @ 75 Hz 720 x 480p @ 60 Hz
1280 x 960 @ 60 Hz 720 x 576p @ 50 Hz
1280 x 1024 @ 60-85 Hz 1280 x 720p @ 50-60 Hz
1920 x 1080p @ 50-60 Hz
2560 x 1600 @ 60 Hz landscape / 1600 x 2560 @ 60 Hz portrait
Ultra-thin frame (bezel), No Touch Auto Adjust™, VESA Mount, tilt,
swivel, height-adjustable stand (7.3 in. / 190mm), pivot, quick-release
stand, zero-watt vacation switch, 12-bit LUTs, black level adjust-
ment, AmbiBright, ColorComp uniformity correction, overdrive, ECO
Mode™, real-time clock, X-Light Pro backlight system, Analog/Digital
CableComp™, GammaComp™ MD software, standalone calibration,
Windows Vista™ Premium-certified
Designed for integration
AC 100-120V / AC 220-240V
143W
1.3W
27.1 x 18.8 - 26.3 x 13.5 in./
687.3 x 478.6 - 668.6 x 342.8mm
27.1 x 17.6 x 5 in./
687.3 x 446.8 x 126mm
42 lbs. / 19.2 kg
31.7 lbs. / 14.4 kg
100 x 100mm and 200 x 100mm
5-35° C / 41-95° F
30-80%
3048m / 10,000 ft.
-10-60° C / 14-140° F
10-85%
12,192m / 40,000 ft.
UL/C-UL, UL60601-1, CE, Gost/PCT, PSB, CCC, TUV GS, FCC Class B/
Canadian DOC, C-tick, MPR II / MPR III, VCCI (class 2), JIS C 61000-3-
2, static electricity guideline, low emission guideline, TUV-Ergonomie,
ISO9241-307, TCO '03, TCO '6, US Mercury regulations, WEEE, RoHs,
SASO, Energy Star 4.0 Tier 2, GEEA, JEITA VOC Guideline. J-Moss,
Windows XP, DEN-TORI, FDA 510k pending
5 years parts and labor, including Advanced Overnight Exchange*****
or less
