Display Setup

Raise and Lower Monitor Screen

The monitor may be raised or lowered. To raise or lower screen, place hands on
each side of the monitor and lift or lower to the desired height (Figure RL.1).
NOTE: Handle with care when raising or lowering the monitor screen.

Tilt and Swivel

Grasp both sides of the monitor screen with your hands and adjust the tilt and
swivel as desired (Figure TS.1).
NOTE: Handle with care when tilting and swiveling the monitor screen.
LCD1570NXmanual051105.pmd
–continued
Figure RL.1
Figure TS.1
