Harris DX 25U Technical Manual page 120

DX-25U
506 0246 000 CAP .47UF 63V 5%
516 0375 000 CAP .01UF 50V -20/+80% Z5U
516 0453 000 CAP .1UF 100V 20% X7R
516 0736 000 CAP .001UF 10% 100V X7R
520 0439 000 CAP, AIR VAR 2.4-24.5PF
522 0531 000 CAP 1UF 50V 20%
526 0342 000 CAP 2.7UF 35V 10%
526 0358 000 CAP 22UF 35V 10%
540 1600 111 RES 27 OHM 3W 5%
540 1600 211 RES 270 OHM 3W 5%
540 1600 212 RES 300 OHM 3W 5%
546 0295 000 RES 50 OHM 3.25W 5%
548 2400 158 RES 39.2 OHM 1/2W 1%
548 2400 169 RES 51.1 OHM 1/2W 1%
548 2400 201 RES 100 OHM 1/2W 1%
548 2400 230 RES 200 OHM 1/2W 1%
548 2400 242 RES 267 OHM 1/2W 1%
548 2400 285 RES 750 OHM 1/2W 1%
548 2400 301 RES 1K OHM 1/2W 1%
548 2400 334 RES 2.21K OHM 1/2W 1%
548 2400 366 RES 4.75K OHM 1/2W 1%
548 2400 373 RES 5.62K OHM 1/2W 1%
548 2400 401 RES 10K OHM 1/2W 1%
548 2400 426 RES 18.2K OHM 1/2W 1%
548 2400 430 RES 20K OHM 1/2W 1%
548 2400 458 RES 39.2K OHM 1/2W 1%
548 2400 501 RES 100K OHM 1/2W 1%
548 2400 601 RES 1MEG OHM 1/2W 1%
558 0041 000 OVEN, XTAL HC6/U 19VDC
604 0852 000 SW, RKR DIP 4-SPST
610 0679 000 PLUG, SHORTING, .25" CTRS
610 0777 000 HDR 3C 1ROW STRAIGHT
610 0979 000 HDR 10C 2ROW VERTICAL
610 0999 000 HDR, 10 PIN, PC BD
612 0904 000 JACK, PC MT GOLD PLATED
612 1206 000 JACK, PC MT FOR .050 PINS
620 1677 000 RECEPTACLE, PC MT, BNC
829 9009 051 BRACKET, OSC. HEATER
839 7930 032 SCHEM, OSCILLATOR
843 5155 032 PWB, OSCILLATOR
999 2450 002 HARDWARE LIST
HARRIS P/N DESCRIPTION
354 0309 000 TERM SOLDER
358 1928 000 JUMPER 1/4 LG 1/8H
358 3052 000 HOLDER, AA SIZE BATTERY
380 0125 000 XSTR, NPN 2N4401 ESD
380 0672 000 XSTR, D45H8 ESD
7-14
Table 7-10. CONTROLLER BOARD - 992 8071 002
WARNING: Disconnect primary power prior to servicing.
1.0 EA C006
2.0 EA C023 C024
10.0 EA C011 C012 C015 C016 C020 C021 C026 C028
C034 C038
1.0 EA C039
2.0 EA C001 C003
2.0 EA C022 C025
2.0 EA C008 C036
1.0 EA C010
1.0 EA R039
2.0 EA R011 R012
2.0 EA R006 R007
5.0 EA R013 R017 R031 R037 R038
1.0 EA R003
3.0 EA R029 R040 R041
2.0 EA R022 R025
1.0 EA R036
1.0 EA R004
2.0 EA R009 R035
10.0 EA R005 R015 R016 R026 R027 R028 R030 R032
R042 R044
2.0 EA R008 R023
2.0 EA R010
R034
1.0 EA R024
5.0 EA R019 R021 R033 R043 R045
1.0 EA R002
1.0 EA R014
1.0 EA R001
1.0 EA R046
2.0 EA R018 R020
2.0 EA #Y001 #Y002
1.0 EA S001
6.0 EA P001 P002 P003 P004 P005 P006
1.0 EA J003
1.0 EA J007
2.0 EA J001 J004
18.0 EA 3XP001 3XP002 3XP003 3XP004 3XP005
3XP006
4.0 EA #Y001 #Y002
2.0 EA J002 J005
2.0 EA
0.0 EA
1.0 EA
1.0 EA
QTY/UM REF. SYMBOLS/EXPLANATIONS
8.0 EA TP001 TP002 TP003 TP004 TP005 TP006
TP007 TP008
6.0 EA JP001 JP002 JP007 JP008 JP009 JP010
3.0 EA BT1 BT2 BT3
1.0 EA Q008
2.0 EA Q001 Q002
888-2297-002 Rev.Y1: 5/24/1999
