Harris DX 25U Technical Manual page 113

548 2400 469 RES 51.1K OHM 1/2W 1%
548 2400 501 RES 100K OHM 1/2W 1%
548 2400 578 RES 634K OHM 1/2W 1%
548 2400 601 RES 1MEG OHM 1/2W 1%
550 0956 000 POT 2000 OHM 1/2W 10%
550 0958 000 POT 10K OHM 1/2 W 10%
604 1064 000 SWITCH, ROCKER DIP 2-SPST
604 1093 000 SW, RKR DIP 6-SPST
610 0978 000 HDR 10C 2ROW RT ANG
610 0984 000 HDR 34C 2ROW VERTICAL
610 0999 000 HDR, 10 PIN, PC BD
610 1053 000 HEADER, 4 PIN, PC BD
610 1070 000 HDR 6 PIN STRAIGHT
610 1110 000 HDR 8C 2R STRT UNPOL
610 1121 000 HDR 4C 2ROW STRAIGHT
612 1184 000 SHUNT JUMPER 0.1" CENTERS
620 0515 000 RECP, SCREW ON SMC
620 1677 000 RECEPTACLE, PC MT, BNC
839 7855 177 SCH, A/D
843 5100 094 PWB, A/D
929 9009 198 XFMR
999 2760 001 HARDWARE LIST, ANALOG TO
HARRIS P/N DESCRIPTION
382 0159 000 IC, 7407 ESD
382 0521 000 IC, 339 ESD
382 0560 000 IC, 74LS27 ESD
382 0580 000 IC, 74LS32 ESD
382 0622 000 IC, 74LS14N ESD
382 0637 000 IC, 74LS30 ESD
382 0774 000 IC 74HC14 ESD
382 1010 000 IC, DS0026CN/MMH0026CP1 ESD
382 1065 000 IC 74HCT273 ESD
384 0205 000 DIODE SILICON 1N914/4148 ESD
384 0651 000 RECTIFIER 1N5401 ESD
384 0719 000 TRANSZORB 1N6373 5V 5W ESD
384 0823 000 LED 10 SEG BARGRAPH, RED ESD
386 0082 000 ZENER, 1N4744A 15V 1W 5% ESD
386 0100 000 ZENER, 1N4747A 20V ESD
398 0019 000 FUSE, FAST CART 2A 250V
402 0129 000 CLIP, 1/4 DIA FUSE
404 0673 000 SOCKET 8 PIN DIP (DL)
Rev.Y1: 5/24/1999
Table 7-5. * MOD ENCODER/BINARY - 992 7089 013
WARNING: Disconnect primary power prior to servicing.
1.0 EA R033
1.0 EA R061
1.0 EA R070
3.0 EA R041 R042 R044
1.0 EA R078
1.0 EA R007
1.0 EA S002
1.0 EA S001
1.0 EA J007
1.0 EA J006
2.0 EA J001 J004
1.0 EA J008
1.0 EA JP010
1.0 EA JP001
1.0 EA JP011
7.0 EA #JP001, 2/#JP011
1.0 EA J003
1.0 EA J002
0.0 EA
1.0 EA
1.0 EA T001
1.0 EA
QTY/UM REF. SYMBOLS/EXPLANATIONS
1.0 EA U059
4.0 EA U062 U063 U064 U065
1.0 EA U053
2.0 EA U060 U061
3.0 EA U054 U055 U057
2.0 EA U066 U067
1.0 EA U056
32.0 EA U001 U002 U003 U004 U005 U006 U007 U008
U009 U010 U011 U012 U013 U014 U015 U016
U017
U018 U019 U020 U021 U022 U023 U024 U025
U026 U027 U028 U029 U030 U039 U040
11.0 EA U031 U032 U033 U034 U035 U036 U037 U038
U049 U050 U051
9.0 EA CR001 CR004 CR005 CR006 CR007 CR008
CR009 CR010 CR011
1.0 EA CR028
2.0 EA CR002 CR003
1.0 EA DS001
8.0 EA CR012 CR013 CR014 CR015 CR016 CR017
CR018 CR019
8.0 EA CR020 CR021 CR022 CR023 CR024 CR025
CR026 CR027
1.0 EA F001
2.0 EA 2#F001
32.0 EA XU001 XU002 XU003 XU004 XU005 XU006
XU007 XU008 XU009 XU010 XU011 XU012
XU013 XU014 XU015 XU016
888-2297-002
Section VII - Parts List
7-7
