WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious
injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building.
Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach you gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Tested by:
919-444a
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
P36D Zero Clearance
Direct Vent Gas Fireplace
MODELS:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
P36D-NG10 Natural Gas
Owners & Installation Manual
P36D-LP10 Propane
07.14.15
Advertisement
Table of Contents
Related Manuals for Regency P36D-LP10
Summary of Contents for Regency P36D-LP10
- Page 1 P36D Zero Clearance Direct Vent Gas Fireplace MODELS: P36D-NG10 Natural Gas P36D-LP10 Propane Owners & Installation Manual www.regency-fire.com WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- Page 2 To the New Owner: Congratulations! ® You are the owner of a state-of-the-art Gas Fireplace by REGENCY FIREPLACE PROD- UCTS The P36D-10 is a hand crafted appliance and has been designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch. The model P36D-10 has been approved by Intertek for both safety and efficiency.
- Page 3 INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This REGENCY ® product has been tested and listed by Intertek to the following standards: VCAN/CGA-2.17-M91, and ANSI Z21.88-2014 • CSA 2.33-2014. and GAS-FIRED APPLIANCES FOR USE AT HIGH ATLITUDES CAN/CGA 2.17-M91. This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada.
-
Page 4: Table Of Contents
Venting Arrangement - Vertical Terminations ....31 Glass Gasket ...............56 Unit installation with Horizontal termination ....32 Main Assembly ............58 Burner Assembly & Log Set.........60 Vignette faceplate and finishing trim ......61 Warranty ..............63 ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 5: Copy Of Safety Decal For P36D-10
0-4500 ft/pi (0-1372 m) Altitude l'altitude Side Wall Clearance from Side Facing B) 6" PROPANE: Model P36D-LP10 APPAREIL FONCTIONNANT AU GAZ PROPANE Alcove Clearances: CONCU POUR ETRE POELE: Modéle P36D-LP10 Max. Depth 36" (914mm) Minimum supply pressure Pression d'allimentation minimum 12"... -
Page 6: Ma Code - Co Detector
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 7: Unit Dimensions With Vignette Faceplate
UNIT DIMENSIONS WITH VIGNETTE FACEPLATE Optional 3 sided finishing trim (not shown) 38" W x 33-3/4" H ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 8: Unit Dimensions With Vignette +Vignette Finishing Trim
UNIT DIMENSIONS WITH VIGNETTE AND VIGNETTE FINISHING TRIM UNIT DIMENSIONS WITH SAFETY SCREEN (#515-929) AND OPTIONAL LOUVERS ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 9: Before You Start
CIALLY THE FIREPLACE GLASS, AND IF THE BARRIER BECOMES DAMAGED, SHOULD STAY AWAY TO AVOID BURNS THE BARRIER SHALL BE REPLACED OR CLOTHING IGNITION. WITH THE MANUFACTURER'S BARRIER FOR THIS APPLIANCE. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 10: Important Message
1) Locate appliance. Refer to the following 13) Do not slam shut or strike the glass door. sections: The P36D-NG10 or P36D-LP10 Direct Vent 14) Under no circumstances should any solid fuels Fireplace must be installed in accordance with a) Locating Your Gas Fireplace (wood, paper, cardboard, coal, etc.) be used in... -
Page 11: Locating Your Gas Fireplace
The kit may be used on either the left or right side. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 12: Clearances
Minimum Clearance from Top of Unit to: Ceiling from top of unit. 32" (1016mm) Side Wall Clearances: 6"* (152mm) * Measured from edge of unit. See Regency Clearances section for dimensions. ® Horizontal Vent Clearances: 2" (51mm) Side 1-1/2" (38mm) Bottom 1-1/2"... -
Page 13: Mantel Leg Clearances
CLEARANCES Min. 6" (152mm) MANTEL LEG CLEARANCES Combustible mantel leg clearances as per diagram: Maximum 1-1/2" projection at 2" minimum clearance. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 14: Combustible Mantel Clearances
MANTEL CLEARANCES WITH MANTEL CLEARANCES WITH VIGNETTE + VIGNETTE FINISHING TRIM SAFETY SCREEN AND LOUVERS FLUSH FINISH Vignette finishing trim, flush finish. Finished material flush to Vignette finishing trim. 14 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 15: Framing
Diagram 5 NOTE: If using flush louvers and safety screen the steel studs and non-combustible material are not required. Wood studs and drywall may be used. See framing and finishing for details. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 16: Framing With Vignette Faceplate
4 sided finish trim the framing would need to be increased by 1-1/4" inches minimum in order for this to fit. This must be to the finished floor. (Eg: Diagram 2 B= 40-3/4" framing height + 1-1/4". Bottom of 4-sided finishing trim +1/2 thick finished floor = 42-1/2". 16 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 17: Finishing
Non-combustible Material J-style Trim or metal corner bead may be used to nish these edges Diagram 2 ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 18: 17-3/8" Wall Mount On / Off Switch Installation
11. Using the two (2) screws provided secure the cover plate to the Receiver. Low Voltage Junction Box Profl ame Receiver J-Box Receiver Slider Switch Wall Plate 10 ft. wire harness with 12 pin connector Diagram 1 18 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 19: Unit Assembly Prior To Installation
Each direct vent gas appliance must use it's own 7/8" / 22mm separate vent system. Common vent systems 1-1/4" / 32mm are prohibited. * For "C" screw position the top facing support is reversed. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 20: Exterior Vent Termination Locations
* Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally 20 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 21: Venting
#8 x 1-1/2" Drill Point, Stainless Steel (4) Notes: 1) Liner sections should be continuous without any joints or seams. 2) Only Flex pipe purchased from FPI may be used for Flex installations. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 22: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
SV4BF TM-4CS Trim Plate-Black 4DT-TP 4DFPB 4DcP SV4LA TM-4TP 22 | Regency Fireplace Products . 6988 Venture St. . Delta, BC . Canada . V4G 1H4 . 604-946-5155 . www.regency-fi re.com ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... - Page 23 Never allow the vent to run downward - this could cause high temperatures and may present a possible fi re hazard. Regency Fireplace Products . 6988 Venture St. . Delta, BC . Canada . V4G 1H4 . 604-946-5155 . www.regency-fi re.com ®...
-
Page 24: Rigid Pipe Venting Systems
, AmeriVent Direct Vent. AstroCap is the proprietary trademark of FPI Fireplace Products International ® Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. 24 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 25: Venting Arrangements Horizontal Termination
• Maintain clearances to combustibles. • Horizontal vent must be supported every 3 feet. • Firestops are required at each floor level and whenever passing through a wall. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 26: Venting Arrangements Vertical Termination
Firestops are required at each floor level and whenever passing through a wall. • Maintain clearances to combustibles. Note: Must use optional rigid pipe adaptor when using rigid vent systems (Part # 510-994). 26 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... - Page 27 45 elbows allowed. • Vent must be supported at offsets • Firestops are required at each floor level and whenever passing through a wall. • Maintain clearances to combustibles. Diagram 1 ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace...
-
Page 28: Horizontal Venting With Two (2) 90 Elbows
Please note min. 1 foot between 90 6' Min. 5' Max. 11' Min. 8' Max. elbows is required. 7' Min. 6' Max. 12' Min. 9' Max. Lengths do not include elbow indicated. 28 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 29: Vertical Venting With Two (2) 90 Elbows
Please note min. 1 foot 5' Min. 6' Max. 8' Min. between 90 elbows is 6' Min. 7' Max. 9' Min. required. 7' Min. 8' Max. 10' Min. Lengths do not include elbow indicated. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 30: Vertical Termination With Co-Linear Flex System Into A Masonry Chimney
Outer Pipe with Kit# 946-563 Air Intake Pipe Length Co-Linear Flex Adapter with Kit# Rigid Pipe Adapter 946-563 # 510-994 90 Degree Elbow Inner Pipe Adapter with Kit# 946-563 30 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 31: Venting Arrangement - Vertical Terminations
VENTING ARRANGEMENT - VERTICAL TERMINATIONS CO-LINEAR FLEX SYSTEM INTO MASONRY FIREPLACES FOR BOTH RESIDENTIAL & MANUFACTURED HOMES Horizontal Distance (Feet) The shaded area in the diagrams show the allowable vertical terminations. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 32: Unit Installation With Horizontal Termination
Failure to do so may result in N E V E R install the snor- termination cap. drafting or performance issues not covered kel upside down. Diagram 3 under warranty. 32 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 33: Unit Installation With Vertical Termination
10" over 16/12 to 18/12 2.13 square and attach over 18/12 to 20/12 2.29 with wood screws Diagram 3 (Diagram 7). over 20/12 to 21/12 2.44 Diagram 7 ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 34: Direct Vent System (Flex) Installation Procedures
1" (25mm) clearance is needed at the termination end. We recommend framing a 10"(254mm) x 10"(254mm) (inside dimensions) hole to give structural rigidity for mounting the termination. 34 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 35: High Elevation
Vent System: Simpson Dura-Vent Direct The gas line connection may be made of rigid Vent System: Simpson Dura-Vent Direct Vent Vent System or Regency Direct Vent System (Flex) pipe, copper pipe or an approved flex connector. System or Regency Direct Vent System (Flex) (If you are using rigid pipe, ensure that the valve can be removed for servicing.) Since some... -
Page 36: Pilot Adjustment
6) When finished reading manometer, turn off the gas valve, disconnect the hose and tighten the screw (clockwise) with a 1/8" flat screwdriver. Note: Screw should be snug, but do not over tighten. 36 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 37: Conversion From Ng To Lp
Remove NG Stepper motor and replace with LP Stepper motor Unscrew the pilot orifice with the allen key; then replace with the LPG pilot orifice and the pilot cap, provided in the kit. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace 10.30.14 919-472... -
Page 38: Optional Brick Panels
Be very careful not to scratch them on the firebox hardware. Note: If the bottom brick panel must be removed: Remove the Rear Log Stand, then remove the Burner Tray. 38 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 39: Log Set Installation
Carefully remove the logs from the box and unwrap them. The logs are fragile, handle with care - do not force into position. Sprinkle the vermiculite over base brick panel. 918-067c Page 1 of 4 01/04/08 ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... - Page 40 02-53. The notch in the bottom right end fi tting against the 5th grate tab. Rear Bracket Cutouts 02-54 02-51 5th Grate Tab 40 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace 918-067c Page 2 of 4 01/04/08...
- Page 41 02-55 02-53 Notch 02-50 02-52 02-54 Rear Grate Tab Photo shows rear grate tab. Log 02-51 was removed to show the positioning of Log 02-52. 918-067c Page 3 of 4 01/04/08 ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace...
- Page 42 If there is any fl ame hesitation, check that area for any blockage of the burner ports. 02-75 02-55 02-50 02-54 02-51 918-067c Page 4 of 4 01/04/08 42 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace...
-
Page 43: Wiring Diagrams
Caution: Ensure that the wires do Wiring errors can cause not touch any hot surfaces and are improper and dangerous away from sharp edges. operation. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 44: Optional Wall Thermostat Installation
Unit will now operate using the wall thermostat. nector - see picture below. NOTE: When the remote receiver is set to ON position, the remote control transmitter and all of its features are now dis- abled. 44 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 45: Optional Fan Installation
THESE FANS COLLECT A LOT OF DUST FROM WITHIN YOUR HOME. ENSURE YOU MAINTAIN THESE FAN MOTORS ON A REGULAR BASIS BY VACUUMING THE FAN BLADES AND THE HOUSING WITH A SOFT BRUSH NOZZLE. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace 10.29.14 919-474... -
Page 46: Standard Flush Door
Use the hook to pull the spring out until you can put the hook into the slot on the bottom door bracket. Repeat for 2nd spring. See diagram 3. Diagram 1 Diagram 3 To remove the flush door, reverse the above steps. 46 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 47: Wall Thermostat (Optional)
(Two-Wire) When Using Wall Thermostat (CP-2 System) Wire Size Max. Length 14 GA. 50 Ft. 16 GA. 32 Ft. 18 GA. 20 Ft. 20 GA. 12 Ft. 22 GA. 9 Ft. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 48: Vignette Faceplate And Safety Screen Installation
P36D P36/P36E 2. Slot the tabs on the inner Vignette frame with safety screen into the corresponding slots in the outer Vignette frame as shown below. Slot 48 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace 11.05.14 919-471... -
Page 49: Vignette Finishing Trim Installation
NOTE: Ensure Inlay is in correct position before pushing studs through the safety screen. Stud Nut + washer (supplied) Completed Install Line up Inlay–Push studs on Inlay through screen ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace 05.21.15 919-559... -
Page 50: Optional Vignette Inlay Installation
Tighten the 3 screws to secure. Completed install Important: See clearance/framing requirements on next page when using the Vignettte Finishing trim Hook Vignette Faceplate brackets into place. 50 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace 04.16.15 919-556... -
Page 51: Optional Finishing Trim
Line up the screw holes on the finishing trim and Vignette Faceplate bracket with the unit–fasten with one screw on each side. Reinstall the glass door and safety screen. Finishing Trim Top Finishing Trim Side ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace 10.29.14 919-475... -
Page 52: Safety Screen Installation - Must Be Used With Optional Louvers
2. The bottom louver has a hinge that is attached (2 screws per hinge) to the lip on bottom of the unit. Note: Top and bottom louvers are different. 52 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 53: Operating Instructions
Option to download remote functions video with QR code below. ON/OFF Button Proflame video Diagram 2 Remote shown in Manual Mode on Hi 6. The unit will turn on. ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 54: Copy Of The Lighting Plate Instructions
Mettre le bouton de commande de gaz en position OFF pour éteindre la veilleuse. Pour économiser le carburant, éteignez la veilleuse quand l’appareil reste longtemps inutilisé. DO NOT REMOVE THIS INSTRUCTION PLATE 919-456 54 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 55: First Fire
Blower: throughout the cycling process. OUT THE GLASS FRONT IN PLACE. Regency gas appliances use high tech blowers to push heated air farther into the room. It is not unusual for the fan to make a "whirring" sound During the first few fires, a white film when ON. -
Page 56: General Vent Maintenance
Wall Straps, or plumbers' tape for GLASS GASKET rigidity. If the glass gasket requires replacement use a tadpole glass gasket for the Flush Front (Part # 936-155). 56 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 57: Removing Valve
17. Close the door and replace the louvers. almost impossible. 18. Fire up the unit again and check for proper screws Rear Log Stand flame appearance and glow on logs. Diagram 2: Rear Log Stand ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 58: Main Assembly
Brick Panel - Left 946-000 Flexible Air Release Duct Brick Panel - Right 511-031 Brick Clips (each) 919-444 Manual 515-969 Conversion Kit - NG to LP *Not available as a replacement part. 58 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... - Page 59 ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace...
-
Page 60: Burner Assembly & Log Set
Remote transmitter (hand held) 911-030 Fan Control Module 910-581 Stepper Motor NG 910-582 Stepper Motor LP 910-073 DC Spark Box 910-074 DC Spark Box Wire *Not available as a replacement part. 60 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 61: Vignette Faceplate And Finishing Trim
Vignette Door Inlay Black Chrome 515-919 Vignette Door Inlay Metallic Black 515-920 Vignette Door Inlay Tuscan Sunset 515-922 Vignette Front Platinum 515-928 Vignette Finishing Trim w/NCB 515-986 3 Sided Finishing Trim Not Shown ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 62: Parts List
SAFETY SCREEN AND LOUVERS Part # Description 515-922 Flush louvers black 515-929 Safety Screen Regency Logo Plate ® 948-223 62 | ® Regency P36D-10 Zero Clearance Direct Vent Gas Fireplace... -
Page 63: Warranty
It is the general practice of FPI to charge for larger, higher priced replacement parts and issue credit once the replaced component has been returned to FPI and evaluated for manufac- turer defect. The authorized selling dealer is responsible for all in-field service work carried out on your Regency product. FPI will not be liable for results or costs of workmanship from unauthorized service persons or dealers. - Page 64 Register your Regency warranty online ® www.regency-fire.com Reasons to register your product online today! • View and modify a list of all your registered products. • Request automatic email notification of new product updates. • Stay informed about the current promotions, events, and special offers on related products.
