STA-RITE
®
INSTALLATION AND USER'S GUIDE
FOR YOUR SAFETY - READ BEFORE OPERATING
Warning:
If you do not follow these instructions exactly, a fire or explosion may result, causing
property damage, personal injury or loss of life.
For additional free copies of this manual; call (800) 831-7133.
120/240 VAC NATURAL GAS/LP GAS
MODELS
200K BTU/HR
250K BTU/HR (ASME)
333K BTU/HR
400K BTU/HR
400K BTU/HR (ASME)
FOR YOUR SAFETY - This product must be
installed and serviced by authorized personnel,
qualified inpool/spa heater installation. Improper
installation and/or operation can create carbon
monoxide gas and flue gases which can cause
serious injury, property damage, or death. For
indoor installations, as an additional measure of
safety, Pentair Aquatic Systems strongly
recommends installation of suitable Carbon
Monoxide detectors in the vicinity of this appliance
and in any adjacent occupied spaces. Improper
installation and/or operation will void the warranty.
Warning: Improper installation, adjustment, alteration, service or maintenance can cause property
damage, personal injury or death. Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
For Your
Safety
10951 W. Los Angeles Ave., Moorpark, CA 93021
P/N S794 Rev. H 8-11-14
MAX-E-THERM
Natural
Propane
SR200NA
SR200LP
SR200HD
460767
460768
SR333NA
SR333LP
SR333HD
SR400NA
SR400LP
SR400HD
460763
460764
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
•
•
Do not touch any electrical switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire department.
DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity
of this or other appliances.
Pentair Water Pool and Spa, Inc.
1620 Hawkins Ave., Sanford, NC 27330
®
POOL AND SPA HEATER
HD
(800) 831-7133 or (919) 566-8000
•
(800) 831-7133 or (805) 553-5000
•
MAX-E-THERM
®
Pool and Spa Heater Installation and User's Guide
1
1 1
OWNER:
Retain For
Future
Reference
