This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.
3.1
Main body (Used figure are KD-AVX40J)
3.1.1 Removing the Bottom chassis (See Fig.1 to 4)
(1) Remove the two screws A and two screws B attaching the
Heat sink. (See Fig.1)
(2) Remove the one screw C attaching the Bottom chassis.
(See Fig.1)
B
(3) Remove the one screw D attaching the Bottom chassis.
(See Fig.2)
(4) Remove the three screws E attaching the Bottom chassis.
(See Fig.3)
(5) Remove the two screws F attaching the Bottom chassis.
(See Fig.4)
(4) Remove the one screw H attaching the Rear bracket. (See

SPECIFIC SERVICE INSTRUCTIONS

DISASSEMBLY

A
C
Fig.1
D
Fig.2
E
Fig.3
SECTION 2
SECTION 3
F
3.1.2 Removing the Main board (See Fig.5 to 8)
(1) Disconnect the card wire from Front chassis connected to
connector
CN962
(2) Disconnect the connector wire from Gear bracket unit con-
nected to connectors
board. (See Fig.5)
(3) Remove the two screws G attaching the Main board. (See
Fig.5)
CN891
G
Fig.6)
Fig.4
of the Main board. (see Fig.5)
CN881
and
CN891
CN962
CN881
Fig.5
(No.MA446<Rev.001>)1-9
F
of the Main
