- Page 1 Hikvision Technical Manual DS-7204HVI-ST Series DVR Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 2 HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or subject...
- Page 3 Hikvision Technical Manual Overview Developed by Hikvision on the basis of the latest technologies, DS-7204HVI-ST Series Digital Video Recorder combines with the advanced H.264 video encoding and decoding standard and maintains high performance rock-solid reliability and longer recording service time.
-
Page 4: Main Features
Partial digital zoom by using mouse when in PTZ control mode Up to 4-ch synchronous playback Support dual stream Different recording storage period configurable for each channel NTP, SADP, DHCP protocols supported ©2006 – 2010 by HIKVISION. All rights reserved. -
Page 5: Hard Disk Management
HDD file system is compatible with Windows. Use pre-allocating hard disk management technology, and no disk fragments. Recording Cycle and non-cycle recording mode. Scheduled and event video encoding parameters. Multiple recording types, including manual, continuous, alarm, motion, ©2006 – 2010 by HIKVISION. All rights reserved. - Page 6 TCP/IP protocol suites, PPPoE, DHCP, DNS, DDNS, NTP, SADP protocols, etc. Unicast and multicast supported; TCP and UDP protocols applicable in unicast transmission. Remote search, playback and download, lock/unlock of video files; ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 7 Built-in WEB Server. Development Provision of SDK in Windows and Linux operating systems. Application software source code of Demo. Support and training service for application system development. ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 8: Rear Panel & Interfaces
④ LINE IN ⑤ AUDIO OUT ⑥ LAN ⑦ VGA Interface ⑧ USB Interface ⑨ RS-232 Serial Interface ⑩ RS-485 Interface, ALARM IN, ALARM OUT ⑪ POWER ⑫ 12VDC Power Supply Interface ⑬ GND ©2006 – 2010 by HIKVISION. All rights reserved. -
Page 9: Specifications
2, USB2.0 Alarm in Alarm out Power supply 12VDC Consumption ≤10W (without hard disk or DVD-R/W) Working -10℃~+55℃ temperature Others Working 10%~90% humidity Size(mm) 45mm(H)×315mm(W)×230mm(D) Weight ≤2.5Kg (without hard disk or DVD-R/W) ©2006 – 2010 by HIKVISION. All rights reserved.
