Special Features - HITEC X2 Ultima Instruction Manual

Set contents
2
3
4
1. X2 Ultima Multi-Charger
2. One XH Adaptor and One
HP/PQ Adaptor
3. Alligator Clip Charging Cable
4. Tamiya Charging Cable
Contents subject to change without notice

Special features

Opt imized operating software
The X2 Ultima features the AUTO function that sets the feeding current during
the charging or discharging process . It can prevent overcharging which may
lead to an explosion due to the user's fault, especially with Lithium batteries.
It can disconnect the circuit automatically and alarm once, detecting any
malfunction. All the programs of this product are controlled through two- way
linkage and communication, to achieve maximum safety and minimize trouble.
All the settings can be configured by the user!
Internal independent lithium battery balancer
The X2 Ultima employs an individual-cell voltage balancer. It isn't necessary to
connect an external balancer for balance charging.
Balancing individual cells during battery discharging
During the process of discharging, the X2 Ultima can monitor and balance each
cell of the battery individually. If the voltage of any single one cell is abnormal,
an error message will be indicated and the process will be ended automatically.
1
5 6
7
8
5. RX Charging Cable
6. Multiplex Charging Cable
7. 18 AWG Wire Charging Cable – 2 pieces
8. Plug-in Battery Clamps
04
SPECIAL FEATURES
