- Page 1 Instruction Manual...
- Page 2 522,6 Anschlussmaße Connection dimensions Cotes du raccordement Dimensioni di allacciamento...
- Page 3 Backfachtür Baking compartment door Porte du compartiment cuisson Sportello vano cottura Feuerraumtür Combustion chamber door Porte du foyer Sportello camera di combustione...
- Page 4 Feuerraum Combustion chamber Foyer Camera di combustione...
- Page 5 Verkleidung Panels Habillage Rivestimento...
-
Page 6: Table Of Contents
C O N T E N T S Drawing explanation Packaging Technical Specification Parts overview 1. IMPORTANT INFORMATION General warning and safety information Before setting up 2. BRIEF HEATING INFORMATION Suitable fuels and fuel quantities Maximum fuel quantity Clean burning Burning wood 3. -
Page 7: Parts Overview
TECHNISCHE DATEN PARTS - OVERVIEW (fig. Page 3 - 5) This is a Design 1 fire and has a connection for fitting to a chimney that is equipped for other fires Description and boilers for solid and liquid fuels, insofar as the 1 Furnace door black B15287 chimney dimensions are in accordance with DIN... -
Page 8: Important Information
I M P O R T A N T I N F O R M A T I O N PRIOR TO SET-UP GENERAL WARNING AND Floor bearing capacity: Ensure that the substructure is capable of bearing SAFETY INFORMATION the weight of the stove prior to set-up. Observe the introductory general warning information Modifications to the firing installation may not be performed. - Page 9 1.2 Flue pipe connection Flue pipes pose a particular source of hazard regarding Use the equipment supplied to open the doors of your gas leaks and fire. Get the advice of an authorised special- stove, e.g. heat-resistant gloves. ist company for the layout and assembly. 1.7 Stoves type 1 (BA 1): Please observe the corresponding installation guidelines These may only be operated with the combustion chamber...
-
Page 10: Brief Heating Information
B R I E F H E A T I N G I N F O R M A T I O N SUITABLE FUELS AND FUELS MAXIMUM FUEL QUANTITIES QUANTITIES Wood: 2 logs of approx. 0.8 kg Your stove is generally suitable for burning dry firewood. You can also burn fuels such as wood briquettes. -
Page 11: Clean Burning
Facing the challenges of our times means assuming re- 2. THE RIGHT QUANTITY OF FIREWOOD sponsibility. Maintaining our natural world is now one of AND FIREWOOD DIMENSIONS our most important tasks. Our products represent devel- opments according to the state of the art. This is the main - Too much firewood leads to overheating. -
Page 12: Connecting The Fire
Part 47 and 31) is in the correct position. When using a flue pipe with throttle valve, the throttle We recommend original flue pipes from RIKA for proper valve must be open. connection. -
Page 13: Operation
4. OPERATION STARTING THE FIRE After this has burned, lay approx 1.8 kg wood (3 billets) (Illustrated: Safety clearances) on the fire. Open the shaker grate handle and the primary air slide until the wood is burning well (approx. 2 mins). In order to keep exhaust emissions as low as possible, we The secondary sir slide remains in the ideal setting. -
Page 14: Ash Drawer
THE FIRE PAINT ONLY HARDENS PROPERLY AF- Caution: Embers could remain in the ash. Only fill the TER HEATING UP DURING USE. ash into non-flammable containers and do not put the ash onto flammable surfaces. Do not touch the surface during heating. It is still soft. Our paints are completely harmless in accordance with the TÜV-certificate;... -
Page 15: Fitting Options
5. FITTING OPTIONS MAKING AN EXTERNAL COMBUSTION AIR FEED (Optional: Fig: Panel) ➧ The line should not be longer than 4 m and have no ➧ Dismantle the rear wall (Item 54) as follows: Lift the bends in order to guarantee adequate air feed. lid (Item 52) off the fire. -
Page 16: Maintenance And Cleaning
Only intact seals guarantee the perfect function of your FINISH – CONDITION AND CLEAN- fire. The door glass can be cleaned using RIKA glass cleaner. The RIKA glass cleaner can be obtained from your spe- cialist fire dealer. Should the glass become heavily sooted the possible cause could be damp wood. -
Page 17: Problem Solving
Solution Always: Every glass plate must be cleaned from time to time (depending 1. Ceramic glass soots over too quickly on use) with RIKA glass cleaner Clarification with chimney sweep (pos- Poor air movement sible raising of chimney) Regulate according to instructions for... -
Page 18: We Guarantee
RIKA dealer in writing using the invoice and stating the purchase date, model name, serial number and reason for Damage arising from non-observance of the complaint. - Page 19 G A R A N T I E G U A R A N / G A R A N T I E G U A R A N T E E Purchase day: / Date d’achat: Kaufdatum: / Purchase day: Trader stamp / Cachet du revendeur Händlerstempel: / Trader stamp: Model designation: / Nom du modèle:...
- Page 20 G A R A N T I E G U A R A N T E E Kunde: / Customer: Marke Stamp An: / To: G U A R A N T E E G A R A N Z I A Client: / Cliente: Marque Marca...
