Removal
27. INSTRUMENT PANEL
Disconnect the cable from the instrument panel (A/F-55).
Then unscrew the 2 screws (B/F-56) securing it to the chassis.
A
28. FRONT TURN INDICATORS
Unscrew the 2 bolts (A/F-57) and tilt the light forwards to aid the operation.
Disconnect the light (B/F-58) from the general wiring.
Unscrew the screw (C/F-59) securing the nut on the inside.
ATTENTION: Pay attention to the position of the cables, to ensure they are refitted
correctly.
F-55
A
F-57
C
F-59
Chassis
B
B
F-56
B
F-58
43
