Removal
Chassis

23. FUEL TRANSMISSION/OIL MIXER

Remove the 2 bolts from the cover (A/F-44).
Pull back the tensioner and withdraw the throttle cable.
A
F-44 F-45

24. CARBURETTOR

* Remove the seat, the front faiings and the fuel tank (only withdraw it). Unscrew the clamp
securing the carburettor to the filter canister. Uscrew the top cover of the carburettor and
extract it with the hatch. Also, unscrew the screw securing the cable to the crankcase and
extract it. Disconnect the suction hose and the remaining pipes.
ATTENTION: Pay attention to the position of the pipes, to ensure they are refitted co-
rrectly.
F-46
40
