34
Removal

11. SILENCER

* Remove the seat and the front right-hand cover.
Loosen the clamp (A/F-23) securing the exhaust pipe to the silencer.
Then unscrew the 2 bolts (B/F-24) securing the silencer to the chassis.
To extract it, pull the silencer backwards.
ATTENTION: Before removing the silencer, make sure it has cooled down.
A
12. "AIS" SYSTEM (Secondary air valve
Disconnected the clamps from the pipes (A/F-25).
Then unscrew the 2 securing screws (B/F-25).
B
A
F-23
A
ATTENTION: Pay attention
to the position of the valve, to
ensure it is refitted correctly. If
it is not fitted correctly, it may
burn out.
F-25
Chassis
B
F-24
