Filter Canister - RIEJU MRT 50 Chassis Workshop Manual

Removal

8. FILTER CANISTER

* Disconnect the rear light and remove it (see section). *Remove the seat and the rear
side covers.
Remove the 2 bolts (A/F-13) from the top.
Unscrew the 2 bolts (B/F-14) located inside the rear wheel arch.
Remove the clamp (C/F-15) between the AIS system pipe connection and the filter nozzle.
Remove the clamp (D/F-16) between the filter nozzle and the carburettor.
To extract the canister, pull it out backwards.
C
A
F-13
F-15
Chassis
B
F-14
D
F-16
31
