20
Familiarising yourself with the moped

CONTROLS

1 2 3
12
11 10 9

KEYS

• The machine is supplied with two keys with a numerical code that allow:
- The ignition to be switched on
- The lights to be switched on
- The steering to be locked

STEERING LOCK

• Locking: With the handlebars turned fully to the left, push the key fully in and turn it
to the left.
• Unlocking: Turn the ignition key to the right.

PROP STAND

• Check that the prop stand is well secured and moves properly. The retention system,
consisting of traction springs, should also be checked frequently.
4 5 6 7
8
F-6
F-7
Chassis
Controls/instrumentos
1. Rear-view mirror
2. Horn button
3. Light switch
(dipped beam/main beam).
4. Main switch.
5. Instrument panel.
6. Front brake cylinder.
7. Throttle twist grip.
8. Front brake lever.
9. Turn indicator switch.
10. Manual choke lever.
11. Clutch lever.
12. Left-hand
handlebar grip.
