IDENTIFICATION OF MAIN ELEMENTS
(left-hand side)
2
1
7
IDENTIFICATION OF MAIN ELEMENTS
(right-hand side)
MRT SM
14
13
3 4
MRT SM
6 5
8
12 11 10
Chassis
1. Headlight.
2. Right-hand controls.
3. Left-hand controls.
4. Seat.
5. Prop stand.
6. Gear change pedal.
7. Fuel tank.
F-4
8. Fuel tank cap.
9. Forks.
10. Radiator.
11. Rear brake pedal.
9
12. Pillion passenger
foot-rests.
13. Exhaust pipe.
14. Number plate holder.
F-5
