Features - Daikin FHQ35BVV1B Technical Data Manual

1

Features

t U n i y S k V 1 B o o r 1 0 A - B V t l i I n d R - 4 F H Q S p • Slim unit with super silent and greater air flow
• Ideal for shops, restaurants or offices requiring maximum floor space
for furniture, decorations and fittings
• Can be installed in both new and existing buildings.
• Compact casing (only 960 to 1,590mm width).
• Extremely quiet in operation
• Auto-swing function ensures efficient air and temperature
distribution.
• Air flow distribution for ceiling heights up to 3.8m without loss of
capacity.
• Up to 4 indoor units can be connected to 1 Multi outdoor unit. All
indoor units are individually controllable with remote control and do
not need to be installed in the same room or at the same time. They
operate simultaneously within the same cooling operation
1
heat pump
2
• Indoor Units • R-410A • FHQ-BVV1B
35˜60
• Split Sky Air • Indoor Units
• Daikin remote controls give you easy control at your fingertips.
• The wired remote control provides you with a schedule timer,
enabling to program the air conditioning daily or weekly.
• The optional remote ON/OFF enables you to start/stop the air
conditioning from a mobile phone via a telephone remote control
(field supply).
• The optional forced OFF enables you to switch off the unit
automatically. E.g. when a window is opened, the unit switches off.
• The 'home leave' operation button prevents large temperature
differences by continuously operating at a minimum (heating mode)
or maximum (cooling mode) preset level while you're out or sleeping.
It also allows the indoor temperature to return quickly to your
favourite comfort level.
2 steps
optional
optional
