Using the HTML5 Toolbox Quick Connect Web-GUI

23.1
The HTML5 Quick Connect Web-GUI is designed for simple peer-to-peer connections and non-
technical users. It has a reduced feature-set and allows users to:
1. Load existing programs in a codec via the Program Loader panel and then dial via the
Quick Connect panel.
2. Use the Quick Connect panel to create and dial a simple peer-to-peer connection using IP/
SIP, ISDN or POTS.
Important Note: Simple peer-to-peer connections are not saved as programs with unique
names. Details of the last ad hoc dial are retained in the Quick Connect panel, even
after a program is loaded and unloaded using the Program Loader panel.
Launching the HTML5 Quick Connect Web-GUI
1. Type the codec IP address in your web-browser.
2. Click to launch the HTML5 Toolbox Quick Connect Web-GUI.
3. Enter the authentication Password for the codec and click OK.
4. The panels in the Quick Connect Web-GUI will automatically be displayed.
Important Note: To change the password using the codec front panel navigate to
Settings > WebGUI > Password and press the
new password and press the
Loading and Unloading an Existing Program
If programs are saved in the codec they are displayed in the Program Loader panel.
1. Click to select a program in the Program Loader panel and click the Load button to load
it in the codec.
© Tieline Pty. Ltd. 2015
Merlin PLUS User Manual v1.4
button. Use the keypad to enter a
button to save the new setting.
199
