Click to configure:
· Auto Jitter Adapt and the preferred auto jitter setting using the drop-down arrow
· Fixed Buffer Level and enter the Jitter Depth, which must be between 12ms and
· Local and Remote FEC settings if required.
ISDN module answering settings are used if you select ISDN as the connection transport.
For more details see
POTS module answering settings are used if you select POTS as the connection
transport. For more details see
8. Continue through the steps in the wizard to complete configuration in the same way as the
first connection was configured. Click Save Program at the end of this process. The newly
created program will be displayed in the left pane within the Programs panel and in the
Master panel.
When this program is loaded any codec dialing in using IP1 (using default Tieline IP port settings)
will be routed to output 1 on the codec and a codec dialing in using IP2 will be routed to output 2.
Important Note: When Tieline Codecs is the Session Protocol selected
(using Tieline session data), the Return Audio Port is automatically
configured as UDP audio port 9010 by default for the second audio stream
connection. Click to deselect the Automatic check-box to adjust this setting.
A codec dialing this connection and using the port specified will always be
routed to output 2 on the codec receiving the call.
for Buffer Priority, or
5000ms depending on the algorithm you select.
Configuring ISDN Answering.
Configuring POTS Answering.
