Checking the SCSI connection

Use the following questions to help you check your SCSI connection. Many users can use HP
Library & Tape Tools to check the SCSI bus type, see page 29. If you answer 'Yes' to all these
questions, you are ready to install your tape drive. If you answer 'No', you will probably need
to purchase and install additional items. For compatibility and product details, go to
www.hp.com/go/connect .
1 Is there a spare SCSI port on
your server?
2 Is the SCSI bus type correct
for the SCSI specification of
the drive?
3 Will the drive be the only
device on the bus? This is the
recommended configuration.
Do not connect to a RAID
controller or the same SCSI
bus as your disk drive.
4 Does the HBA/controller have
a VHD SCSI connector?
5 You are ready to install the
drive.
SCSI Bus Type
Ultra wide LVD
Ultra 2 LVD, Ultra 3 (160) LVD,
Ultra 4 (320) LVD
Ultra wide, single-ended
Ultra narrow, single-ended
High Voltage Differential
table 1: supported SCSI bus types
Yes
Yes
Yes
Yes
Yes. This is a recommended configuration as long as the drive is
the only device on the SCSI bus.
Yes. These are recommended configurations, particularly if there
are several devices on the SCSI bus.
Yes. But this is not a recommended configuration as it will restrict
performance.
Yes. But this is not recommended as it will severely restrict
performance and you will need a suitable cable or adapter.
No. The drive will not work and you may damage the drive or
controller
Purchase and install one of the recommended
HBAs into an unused 64-bit PCI expansion
No
slot. (The HBA can also be installed in a 32-
bit PCI expansion slot, but performance may
be degraded.)
See table below. If the SCSI bus differs from
No
the recommended specification for the drive,
performance of either the drive or the bus may
be impaired. Consider replacing your card
with one of the recommended HBAs.
If you have an Ultra HBA, performance may
be impaired. Consider installing (if you have
No
a spare PCI slot) or replacing your card with
an Ultra 2, Ultra 3 (160) or Ultra 4 (320)
HBA. Make sure the last device on the bus is
terminated.
No
Purchase and install a VHD-to-HD adapter or
use an HD-to-HD cable instead of the supplied
VHD-to-HD cable.
Supported
