11.11 Instruct the User
Instruct and demonstrate the lighting procedure, then
advise the user of the efficient and safe operation of
the boiler.
Instruct and demonstrate the operation of any heating
system controls.
Advise the user on the use and maintenance of any scale
reducer and pass on any relevant
instructional documents.
Advise the user that to ensure the continued efficient and
safe operation of the appliance it is recommended that it
is checked and serviced at regular intervals.
The frequency of servicing will depend upon the
particular installation and usage, but in general once a
year should be enough.
Draw attention, if applicable, to the current issue of the
Gas Safety (Installation and Use) Regulations, Section
35, which imposes a duty of care on all persons who let
out any property containing a gas appliance.
It is the Law that any servicing is carried out by a
competent person.
Advise the user of the precautions necessary to prevent
damage to the system and building in the event of the
heating system being out of use during frost and
freezing conditions.
Reminder - Leave these instructions with the user..
1 1 C o m m i s s i o n i n g
HINGE PIN RETAINING
BRACKET
BRACKET
SECURING
SCREW
HINGE PIN
SCREW
(2)
27
NUT &
PLASTIC COVERS
WASHER(2)
COVER
PLATE
OUTER CASE
HINGE
SECURING
PIN
SCREWS (4)
PLASTIC
BUSH (2)
CATCH
ASSEMBLY
SECURING
NUT
SPACER
Diagram 11.6
221138C
