S.5 Speaker |
FEATURES:
solution • S.5 is timbre-matched to the other "S" models •
Magnetically Shielded – all drivers • Built-In Wall Mounting System for
flexible and secure wall mounting - Will allow horizontal and vertical
movement – no tools required! • Bass Reflex design – Rear vented
COMPONENTS:
• 1-1" Teteron Dome Tweeter • 1-4" Composite Cone
Woofer • MDF Construction • Composite Resin Front and Rear Baffles • Binding
Post terminals
• Frequency response: 80-20kHz +/- 3dB • Power handling: 100
SPECIFICATIONS:
watts per channel RMS • Sensitivity: 86dB anechoic – 89 dB room measurement
• Crossover point: 2.0kHz • Impedance: 8 ohms compatible • Dimensions:
- Width: 5-3/4" (14.6 cm) - Height: 8-1/2" (21.6 cm) - Depth: 6-1/4" (15.9 cm) -
Weight: 6 lbs (2.7 kg) each • Color: High Gloss Black with Silver or Black Injection
Molded Baffles
C.5 Center Channel Speaker |
High Power center channel speaker to match the S.5
speaker • C.5 is timbre matched to the other "S" models
as well • Magnetically Shielded – all drivers • Key-Way
wall mount • Bass Reflex design – Dual rear vents
• 1-1" Teteron Dome Tweeter • 2-4" Composite Cone Woofers • MDF
COMPONENTS:
Construction • Composite Resin Front and Rear Baffles • Binding Post terminals
• Frequency Response: 80-20kHz +/- 3dB • Power Handling: 100
SPECIFICATIONS:
watts per channel RMS • Sensitivity: 86dB anechoic – 89 dB room measurement
• Crossover Point: 2.0kHz • Impedance: 8 ohms compatible • Dimensions: - Width: 15"
(38.1 cm) - Height: 5-5/8" (14.3 cm) - Depth: 6-1/4" (15.6 cm) - Weight: 9.5 lbs
(4.3 kg) each • Color: High Gloss Black with Silver or Black Injection Molded Baffles
Recommended subwoofers (optional)
AS-P300 – 300 watt 8" vented subwoofer
AS-P400 – 400 watt 10" vented subwoofer
(used for rooms over 400 sq feet in size)
Both models feature athena TECHNOLOGIES
SCT control, for precise blending of the
system to the subwoofer.
athena TECHNOLOGIES
3641 McNicoll Avenue
Toronto, Ontario
Canada M1X 1G5
www.athenaspeakers.com
Printed in Canada. Subject to change without notice.
© 2003 athena TECHNOLOGIES
Part #3PAB006E
• Small, High Power Full-Range speaker
• Small –
FEATURES:
TM
exclusive
5MK II
POINT
®
®
Create your sound.
POINT 5 MK I I
