INPUT POWER REQUIREMENTS-

At AC Transformer:
At Power Jack On Stick:
POWER CONSUMPTION-
CO INTERFACE-
Ringer Equivalence Number:
Input Ring Detection:

DEVICE INTERFACE-

Battery:
Off-Hook Detection:
110-125 Volts AC Only, 50-60 Hz
12-14 Volts AC and DC
6.2 Watts
0.5 B
40-150 Volts AC, 15-68 Hz
-48 Volts Nominal DC To All Devices
3-80 mA
Ring Generator Frequency:
Waveform:
Ringing No Load:
Ringing 8000 Ohm Impedance (REN 1.0): Approx. 8 1.6 Volts RMS AC
Ringing 4000 Ohm Impedance (REN 2.0): Approx. 73.0 Volts RMS AC
Ringing 2667 Ohm Impedance (REN 3.0): Approx. 64.5 Volts RMS AC
Ringing 2000 Ohm Impedance (REN 4.0): Approx. 55.0 Volts RMS AC
Ringing 1800 Ohm Impedance (REN 5.0): Approx. 49.5 Volts RMS AC
30 Hz (+/- . . 1 ) Hz Voltage Regulated
and Current Limited
True Sinusoidal
Approx. 82.8 Volts RMS AC
