THE STICK PROGRAMMING AND QUICK REFERENCE GUIDE
REGISTER # PROGRAMMABLE
FEATURE
FAX Tone Detection
01
Protected Hook
02
Flash
Unanswered Call
03
Silent Transfer
Silent Transfer
04
Destination
Pulse Detection
05
Call Override
06
Unrestricted Manual
07
Transfer
Answering Machine
08
Silent Transfer
Security Access Code
11
for VOICE Ports
Security Access code
12
for FAX Port
Security access code
13
for MODEM Port
Rings to answer
14
Maximum rings
15
PROGRAM FACTORY
RANGE PRESET
0 = off
ON
1 = on
0 = off
OFF
1 = on
0 = off
OFF
1 = on
0 = fax
FAX
1 = modem
0 = off
OFF
1 = on
0 = off
OFF
1 = on
0 = off
ON
1 = on
0 = off
OFF
1 = on
Digits 0-9 *
*1
and #
4 digits max.
Digits 0-9 *
*2
and #
4 digits max.
Digits 0-9 *
*3
and #
4 digits max.
0 to 10 Rings
0 Rings
4 to 30 Rings
8 Rings
7
PROGRAMMING / INSTALLATION
RECOMMENDATIONS
Regardless of how you install the Stick, if a FAX/PC
FaxCard is used—Program this feature "ON"
With older KEY and PBX systems, you may need to
program this feature "ON"
"UCST" routes all unanswered after-hours calls to
fax or modem ports (on any installation)-—
program "ON"
This feature determines what device will receive a
call after it has been "silently transferred"
If you have pulse-dial phones and wish to transfer
or "grab" a call—program this feature "ON"
If The Stick is installed at a walljack and you want
to answer a call from any extension phone—
program "ON"
Gives transfer ability at any time, from either party
from any phone, recommended programming
"ON"
After answering machine times out, call will be
routed to fax or modem port (any installation)—
program "ON"
This register contains the code for transfer of a
voice or modem call to devices connected to voice 1
& 2 ports
This register contains the code for transfer of a
voice or modem call to FAX/PC FaxCard
CONNECTED to fax port
This code is usually sent by calling modem—we
recommend programming a 4 digit code for
security purposes
If the stick is used on a KSU or PBX set to "0" –
home installs w/ext. phone access, program needed
no. of rings
This feature controls the number of times a device
(voice, fax, modem) is rung by the stick before
dropping the call
YOUR
PROGRAM
