Issue B1
NOTES
In some cases - when changing parameter values - the display on the BOP shows
Changing single digits in Parameter values
For changing the parameter value rapidly, the single digits of the display can be
changed by performing the following actions:
Ensure you are in the parameter value changing level (see "Changing parameters
with BOP").
1. Press
2. Change the value of this digit by pressing
3. Press
4. Perform steps 2 to 4 until the required value is displayed.
5. Press the
NOTES
The function button may also be used to acknowledge a fault condition
3.2.2.2 Commissioning with the AOP
3.2.3 Commissioning functions with BOP / AOP
3.2.3.1 Quick commissioning (P0010=1)
It is important that parameter P0010 is used for commissioning and P0003 is used
to select the number of parameters to be accessed. This parameter allows a group
of parameters to be selected that will enable quick commissioning. Parameters
such as Motor settings and Ramp settings are included.
At the end of the quick commissioning sequence, P3900 should be selected,
which, when set to 1, will carry out the necessary motor calculations and clear all
other parameters (not included in P0010=1) to the default settings. This will only
happen in the Quick Commissioning mode.
MICROMASTER 440 Operating Instructions
6SE6400-5AC00-0BP0
. This means the inverter is busy with tasks of higher priority.
(function button), which causes the right hand digit to blink.
(function button) again causes the next digit to blink.
to leave the parameter value changing level.
The AOP is available as an option. Its advanced features
include the following:
Ø Multilingual clear text display
Ø Upload/download of multiple parameter sets
Ø Programmable via PC
Ø Multidrop capability to drive up to 30 inverters
Please refer to the AOP Manual for details or contact your
local Siemens sales office for assistance.
3 Commissioning
/ .
43
