User Manual for Wrist Oximeter
Instructions to User
PC-68B Wrist Oximeter is a precision measuring device,
please read the manual very carefully before using this
device. Failure to follow these instructions may cause
measuring abnormality or damage to the oximeter.
No part of this manual may be photocopied, reproduced or
translated into another language without the prior written
consent. Shenzhen Creative Industry Co., Ltd. reserves the
right to improve and amend it at any time without prior
notice.
Version of This Manual: Ver 1.4
Revised date: July 26, 2012
All rights reserved.
3502-2290033
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC-68B and is the answer not in the manual?

Questions and answers

Related Manuals for Creative PC-68B

Summary of Contents for Creative PC-68B

  • Page 1 User Manual for Wrist Oximeter Instructions to User PC-68B Wrist Oximeter is a precision measuring device, please read the manual very carefully before using this device. Failure to follow these instructions may cause measuring abnormality or damage to the oximeter.
  • Page 2  The contents contained in this manual are subject to change without prior notice.  Information furnished by Creative is believed to be accurate and reliable. However, no responsibility is assumed by us for its use, or any infringements of patents or other rights of third parties that may result from its use.
  • Page 3 User Manual for Wrist Oximeter Warnings  For individual patients, there should be a more prudent inspecting in the placing process. The device can not be clipped on the edema and tender tissue.  The light (the infrared light is invisible) emitted from the sensor is harmful to the eyes, so the user or even the service engineer should not stare at the light emitting components.

  • Page 4: Declaration Of Conformity

    User Manual for Wrist Oximeter  High temperature high pressure steam disinfection to the oximeter is not permitted. Refer to related chapter for instructions of cleaning and disinfection. Declaration of Conformity: The manufacturer hereby declares that this device complies with the following standards: IEC 60601-1 ISO 9919 and follows the provisions of the council directive...

  • Page 5: Table Of Contents

    User Manual for Wrist Oximeter Table of Contents 1 OVERVIEW ..............1 1.1 Appearance .............. 1 1.2 Name and Model ............2 1.3 Conformation ............3 1.4 Features ..............3 1.5 Intended Use ............4 1.6 Key of Symbols ............5 2 BATTERY INSTALLATION........

  • Page 6: Overview

    User Manual for Wrist Oximeter 1 Overview 1.1 Appearance Figure 1 Front View 1. LCD screen 2. Set key: shift display modes, confirm the operation etc. 3. Scroll key: short press: move display cursor, modify parameter values etc. Longtime press: choose display always on or not which will be effective during measuring.

  • Page 7: Name And Model

    User Manual for Wrist Oximeter Figure 2 Frontal Side View 4. Buzzer 5. Data interface 6. Wristband Underlay Figure 3 Right Side View 7. SpO probe receptacle 1.2 Name and Model Name: Wrist Oximeter Model: PC-68B...

  • Page 8: Conformation

    User Manual for Wrist Oximeter 1.3 Conformation It comprises the main unit and SpO probe. 1.4 Features Wrist Oximeter can be used to monitor pulse oxygen saturation (SpO ) and pulse rate accurately. Simply put your finger into sensor, SpO value and pulse rate value will be displayed on screen and stored in the device.

  • Page 9: Intended Use

    User Manual for Wrist Oximeter  PR trend curve and SpO trend curve view;  Data storage and transmission to PC for view and analysis(Optional);  Smart battery power management with low battery indication; 1.5 Intended Use This Wrist Oximeter is intended for measuring the pulse rate and functional oxygen saturation (SpO ).

  • Page 10: Key Of Symbols

    User Manual for Wrist Oximeter 1.6 Key of Symbols Symbol Description %SpO Pulse Oxygen Saturation Perfusion Index Pulse Rate Pulse rate symbol Low battery voltage Symbol for display always on Memory full. Serial number Date of manufacture Authorised representative in the European community Manufacturer (including address) With Type BF applied part...

  • Page 11: Battery Installation

    User Manual for Wrist Oximeter 2 Battery Installation Figure 4 Battery Installation 1. Lift up the cloth covered on the battery cover. Then, use your index finger and middle finger to press against the battery cover. Meanwhile, slide it towards the side with probe (as shown in Figure 4).

  • Page 12: Operation

    User Manual for Wrist Oximeter 3 Operation 3.1 Measuring Operation 1. Insert the external SpO probe connector into SpO probe receptacle properly. Figure 5 Sp0 Probe Connection 2. Fix the oximeter on your left wrist (Figure 6); 3. Then, hold the probe with its opening towards your index finger.
  • Page 13 User Manual for Wrist Oximeter Finger tip sign Figure 6 Placement Demonstration 4. Next, insert your index finger into the probe until the fingernail tip rests against the stop at the end of the probe (Figure 7). Adjust the finger to be placed evenly on the middle base of the sensor (make sure the finger is in the right position).
  • Page 14 User Manual for Wrist Oximeter Wrong Placement of the Probe: Finger out Not deep enough Figure 8 5. The oximeter will automatically start measurement in 2 seconds. Then the default screen will be displayed (Figure 9A). User can read the values and view the waveform from the display screen.
  • Page 15 User Manual for Wrist Oximeter Key Operations:  Short time press “ ■ ” key to switch display modes circularly, display screen will be switched among the screens as shown in Figure 9A, Figure 9C and Figure  Longtime press “ ▲...
  • Page 16 User Manual for Wrist Oximeter Figure 9C  “PI%”: Perfusion index symbol; Figure 9D Real Time Clock  “12:30”: the current time; Key Operations:  Longtime press “ ■ ” key, menu screen will be displayed, refer to section 3.2 for details; -11-...
  • Page 17 User Manual for Wrist Oximeter 6. Prompt information  During monitoring, if you haven’t inserted your finger into the probe, “Finger out ” will be prompted on the screen.  During monitoring, if the probe is not connected to the oximeter or the probe is off, “No Signal!” will be prompted on the screen, as shown in Figure 10.
  • Page 18 User Manual for Wrist Oximeter Figure 11 Memory Full Note: It is suggested that the data shall be uploaded to computer for saving, or the earliest records will be overwritten. Working Mode  The measurement will start automatically when the finger is inserted into the soft rubber of the sensor, so the data recording (SpO and PR values) starts...
  • Page 19 User Manual for Wrist Oximeter any key will activate the display for viewing the current measuring information again.  If there is no signal to be detected (e.g. finger off) for 20 seconds, the device will be at idle state (i.e. blank screen and standby for measurement).

  • Page 20: Menu Operation

    User Manual for Wrist Oximeter 3.2 Menu Operation ■ On display screen, longtime press “ ” key menu screen will be displayed on the screen, as shown in Figure 12. Figure 12 Menu Screen  Rec Interval: set the interval to record SpO pulse rate data;...
  • Page 21 User Manual for Wrist Oximeter 3.2.1 Record Interval Settings ■ On menu screen, select “Rec Interval” and press “ ” key to enter Record Interval Setting screen, as shown in Figure Figure 13 Record Interval Setting Operation Instructions:  Short time press “ ■...
  • Page 22 User Manual for Wrist Oximeter 3.2.2 Over-limit indication Settings ■ On menu screen, select “Alarm Limit” and press “ ” key to enter Alarm Limit Settings screen, as shown in Figure Figure 14 Over-limit indication Settings  SpO limit; Setting range:85%~95%, default setting: 85%;...
  • Page 23 User Manual for Wrist Oximeter Operation Instructions:  Short time press “ ▲ ” key: shift cursor circularly;  Short time press “ ■ ” key: active the option;  Short time press “ ▲ ” key: increase numerical value one time;...
  • Page 24 User Manual for Wrist Oximeter 3.2.3 Time Settings ■ On menu screen, select “Time” and press “ ” key to enter Time Settings screen, as shown in Figure 15. Figure 15 Time Settings  Date format: MM/DD/YYYY;  Time format: hh:mm:ss; Operation Instructions: ...
  • Page 25 User Manual for Wrist Oximeter 3.2.4 Trend Review ■ On menu screen, select “Trend Review” and press “ ” key to enter Trend Review screen, as shown in Figure 16. Figure 16 Trend Review Screen  “03/06/2008”: date of the measurement ...

  • Page 26: Upload Data

    User Manual for Wrist Oximeter 3.2.5 Delete Data On menu screen, select “Delete Data” and press “■” key to enter into Deletion Confirmation screen. Then, select “Yes” with “▲” key(short time press), after short time pressing “■” key, all the records will be deleted. Figure 17 Delete Records 3.3 Upload Data Before uploading the data to PC, please quit from the menu...

  • Page 27: Low Battery Indication

    User Manual for Wrist Oximeter 3.4 Low Battery Indication If “ ” occurs on the screen, it indicates battery power is not enough, please change batteries. If you keep on using, after a while, when the batteries are exhausted, “Low Battery!” indication will be displayed and the oximeter will be off in 5 seconds.

  • Page 28: Additional Advice For Operation

    User Manual for Wrist Oximeter 4 Additional Advice for Operation  The finger should be put properly and correctly.  Avoid shaking finger as possible as you can during measuring;  Do not put wet finger directly into sensor.  Avoid placing the device on the same limb which is wrapped with a cuff for blood pressure measurement or during venous infusion.

  • Page 29: Technical Specifications

    User Manual for Wrist Oximeter 5 Technical Specifications A. Display mode：Color OLED Display B. Power supply requirement: 2 x LR03 (AAA) alkaline batteries or Ni-MH rechargeable batteries Supply voltage: 3.0VDC Continues working time (display is off): 70hours C. Operating current: ≤40mA D.
  • Page 30 User Manual for Wrist Oximeter F. Preset limits: Low limit setting: Pulse Rate limit setting range: Upper limit: 120bpm Lower limit: 50bpm G. Update rate: 6 seconds moving average for SpO and 8 beats average for Pulse Rate readings. H. Perfusion Index Display Range: 0.2%~20% Performance under low perfusion condition The accuracy of SpO...
  • Page 31 User Manual for Wrist Oximeter L. Dimensions: W 59mm×D 49mm×H 22mm Net Weight: about 60g (not including batteries) M. Classification The type of protection against electric shock: Internally powered equipment. The degree of protection against electric shock: Type BF applied part. The degree of protection against harmful ingress of liquids: Ordinary equipment without protection against ingress of water.

  • Page 32: Accessories

    User Manual for Wrist Oximeter 6 Accessories  A data cable (optional)  Oximeter Data Manager software (optional)  A Wristband  A SpO Probe  Two batteries (AAA)  A User Manual  Quality Certificate Note: The accessories are subject to change. See the Packing List for detailed items and quantity.

  • Page 33: Repair And Maintenance

    User Manual for Wrist Oximeter 7 Repair and Maintenance 7.1 Maintenance The service life (not a warranty) of this device is 5 years. In order to ensure its long service life, please pay attention to the maintenance.  Please change the batteries when the low-voltage indicator lightens.

  • Page 34: Cleaning And Disinfecting Instruction

    User Manual for Wrist Oximeter 7.2 Cleaning and Disinfecting Instruction  Surface-clean sensor with a soft gauze by wetting with a solution such as 75% isopropyl alcohol, if low-level disinfection is required, use a 1:10 bleach solution. Then surface-clean with a damp cloth and dry with a piece of cloth.

  • Page 35: Troubleshooting

    User Manual for Wrist Oximeter 8 Troubleshooting Trouble Possible Reason Solution The SpO 1. The finger is not 1. Place the finger and Pulse Rate placed far enough correctly inside and display inside. try again. instable 1. The batteries are drained or almost 1.
  • Page 36 User Manual for Wrist Oximeter Trouble Possible Reason Solution 1. Connect the 1. The probe is not probe to the connected to the oximeter properly oximeter properly. and try again.; Always 2. The finger is not 2. Place the finger display placed well.

  • Page 37: Appendix

    User Manual for Wrist Oximeter 9 Appendix A Common Knowledge for SpO Measurement 1 Meaning of SpO is the saturation percentage of oxygen in the blood, so called O concentration in the blood; it is defined by the percentage of oxyhemoglobin (HbO ) in the total hemoglobin of the arterial blood.
  • Page 38 User Manual for Wrist Oximeter passes. Due to that oxygenated hemoglobin (HbO ) and deoxygenated hemoglobin (Hb) have different absorption character in the spectrum range from red to infrared light (600nm~1000nm wavelength), using these characteristics, SpO can be determined. SpO measured by this oximeter is the functional oxygen saturation -- a percentage of the hemoglobin that can transport oxygen.
  • Page 39 User Manual for Wrist Oximeter Factors affecting measuring accuracy (interference reason)  Intravascular dyes such as indocyanine green or methylene blue  Exposure to excessive illumination, such as surgical lamps, bilirubin lamps, fluorescent lights, infrared heating lamps, or direct sunlight. ...
  • Page 40 User Manual for Wrist Oximeter 4 Factors causing low SpO Measuring value (pathology reason)  Hypoxemia disease, functional lack of HbO  Pigmentation or abnormal oxyhemoglobin level  Abnormal oxyhemoglobin variation  Methemoglobin disease  Sulfhemoglobinemia or arterial occlusion exists near sensor ...

  • Page 41: B Wristband Installation And Disassembly

    User Manual for Wrist Oximeter B Wristband Installation and Disassembly Step 1: Fix the wristband on your left wrist(Fig.A). Fig. B Wristband underlay Wristband Fig. A Fig.C Step 2: Put the oximeter on the propriate site of the wristband. Then press the oximeter to make the wristband underlay(Fig.B) stick to the wristband firmly.
