User Manual for Fingertip Oximeter
Instructions to User
Dear Users,
Thank you very much for purchasing our product. Please
read the manual very carefully before using this device.
Failure to follow these instructions can cause measuring
abnormality or damage to the oximeter.
The manual is published in English and we have the
ultimate right to explain the Manual. No part of this
manual may be photocopied, reproduced or translated into
another language without the prior written consent. We
reserve the right to improve and amend it at any time
without prior notice.
Version of the Manual: Ver 1.0
Revised date: October 24, 2012
All rights reserved.
3502-2290052
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC-60NW-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Creative PC-60NW-1

Summary of Contents for Creative PC-60NW-1

  • Page 1 User Manual for Fingertip Oximeter Instructions to User Dear Users, Thank you very much for purchasing our product. Please read the manual very carefully before using this device. Failure to follow these instructions can cause measuring abnormality or damage to the oximeter. The manual is published in English and we have the ultimate right to explain the Manual.
  • Page 2 User Manual for Fingertip Oximeter Warnings  Check the device before using it to make sure that there is no visible damage which may affect user’s safety or its performance with regard to sensors and clips. It is recommended that the device should be inspected minimally once a week.

  • Page 3: Instructions For Operation

    User Manual for Fingertip Oximeter  DO NOT clip this device on edema or tender tissue.  The light (the infrared light is invisible) emitting from the device is harmful to the eyes, so service technician or testee should not stare at the light. ...
  • Page 4 User Manual for Fingertip Oximeter  Keep the oximeter away from dust, vibration, corrosive substances, explosive materials, high temperature and moisture.  Existence of high intensive light sources, such as fluorescence light, ruby lamb, infrared heater or strong sunshine, etc. may cause inaccuracy of measurement result.
  • Page 5 User Manual for Fingertip Oximeter Declaration of Conformity: The manufacturer hereby declares that this device complies with the following standards: IEC 60601-1 IEC 60601-1-2 ISO 9919 and follows the provisions of the council directive MDD 93/42 EEC Caution: U.S. federal law restricts this device to sale or use by or on the order of a physician.

  • Page 6: Table Of Contents

    User Manual for Fingertip Oximeter Content 1 Overview ..............1 1.1 Appearance ............1 1.2 Name and Model ..........2 1.3 Intended Use ............2 1.4 Structure and Conformation ....... 2 1.5 Features ..............2 2 Battery Installation ............. 3 3 Operation ..............
  • Page 7 User Manual for Fingertip Oximeter 6.2 Cleaning and Disinfecting Instruction ....15 7. Troubleshooting ............16 Appendix ..............17 A. Key of Symbols ............. 17 B. SpO Common Knowledge ........18...

  • Page 8: Overview

    User Manual for Fingertip Oximeter 1 Overview 1.1 Appearance Figure 1 Front/Rear View...

  • Page 9: Name And Model

    User Manual for Fingertip Oximeter 1.2 Name and Model Name: Fingertip Oximeter Model: PC-60NW 1.3 Intended Use This Fingertip Oximeter is intended for measuring the pulse rate and functional oxygen saturation (SpO through patient’s finger. It is applicable for spot-checking and pulse rate of adult and pediatric patients in homes and clinics.

  • Page 10: Battery Installation

    User Manual for Fingertip Oximeter • 2AAA alkaline batteries with low power consumption • Low battery voltage indication 2 Battery Installation Figure 2 Battery Installation 1. Refer to Figure 2, insert two AAA size batteries into the battery compartment properly. 2.

  • Page 11: Operation

    User Manual for Fingertip Oximeter 3 Operation 3.1 Directly Measurement 1. Open the clip as shown in Figure 3. Figure 3 Put finger into the Oximeter 2. Put finger into the rubber cushions of the clip (make sure the finger is in the correct position), and then clip the finger.
  • Page 12 User Manual for Fingertip Oximeter automatically as shown in figure 4C. Press the key again, the screen will change its direction as shown in 4D. It obviously shows that the alternative display between parameter PR and PI is under the condition that the direction of screen is rotated to the left and right side, which is accompanied by no waveform displayed as shown in 4B and 4E.
  • Page 13 User Manual for Fingertip Oximeter Screen Description:  “%SpO ”: SpO symbol; “99”: SpO value;  “PR”: Pulse Rate icon; “65”: Pulse Rate value;  “ ”: Pulse beat symbol;  “ ”: Pulse intensity bar graph;  “PI%”: Perfusion index icon; “1.4”: Perfusion Index value;...
  • Page 14 User Manual for Fingertip Oximeter No display“ ”icon 1."Wireless" function disabled; 2. The device fails to setup a wireless connection with the surrounding host within 3 minutes; 3. Hardware failure of wireless transmission function while the “Wireless” function is enabled.

  • Page 15: Over-Limit Indication And Beep Silence

    User Manual for Fingertip Oximeter 3.2 Over-limit indication and Beep Silence When measuring, if SpO value or pulse rate value exceeds the preset alarm limit, the device will beep automatically and the value which exceeds limit on the screen will flash. The detailed information refers to chapter 4.

  • Page 16: Setup Menu Screen

    User Manual for Fingertip Oximeter 3.3 Setup Menu Screen Figure 5 Menu Screen Long time pressing display key could enter the setup menu screen. Setup Menu Screen Description： “Wireless”：The wireless on-off button. There are 2 selectable options: “on” and “off”. The device transmits data to PC when it is on.

  • Page 17: Data Transmission

    User Manual for Fingertip Oximeter modify the value within 30~60 with “1” as a step. “Save, exit menu”：Longtime pressing this item to store settings and exit to the normal display screen from the setup menu. On setup menu screen: Short time press Display Key to choose the setting item;...

  • Page 18: Technical Specifications

    User Manual for Fingertip Oximeter 4. Technical Specifications A. SpO measurement Technique: dual-wavelength LED sensor with wavelength: Red light: 663 nm, Infrared light: 890 nm. Maximal optical output power: <= 1.5mW Measuring range: 35%~100% Measuring accuracy: <= 3% for SpO range from 70% to 100% Note: A is defined as root-mean-square value of...
  • Page 19 User Manual for Fingertip Oximeter D. Audible &visual over-limit indication When measuring, if SpO value or pulse rate value exceeds the preset limit, the device will beep automatically and the value which exceeds limit on the screen will flash. The oximeter will shut down automatically in 8 seconds with no signal.

  • Page 20: Accessories

    User Manual for Fingertip Oximeter J. Dimensions: 60 mm (L) × 33 mm (W) × 30 mm (H) Net Weight: 35g (including battery) K. Classification: The type of protection against electric shock: Internally powered equipment. The degree of protection against electric shock: Type BF applied parts.
  • Page 21 User Manual for Fingertip Oximeter The service life (not a warranty) of this device is 5 years. In order to ensure its long service life, please pay attention to the use of maintenance.  Please change the batteries when the low-voltage indicator lightens.

  • Page 22: Cleaning And Disinfecting Instruction

    User Manual for Fingertip Oximeter  Necessary servicing must be performed by qualified service engineers ONLY. Users are not permitted to maintain it by themselves. High-pressure sterilization cannot be used on the device. Do not immerse the device in liquid. 6.2 Cleaning and Disinfecting Instruction ...

  • Page 23: Troubleshooting

    User Manual for Fingertip Oximeter 7. Troubleshooting Trouble Possible Reason Solution 1. Place the 1. The finger is finger correctly The SpO not placed far inside and try and Pulse enough inside. Rate display 2. The finger is again. instable shaking or the 2.

  • Page 24: Appendix

    User Manual for Fingertip Oximeter No display Please contact the of the local service Hardware failure wireless center. of wireless transmission “ ” icon function. when it is enabled Appendix A. Key of Symbols Symbol Description With Type BF applied part Warning ─...

  • Page 25: Spo Common Knowledge

    User Manual for Fingertip Oximeter B. SpO Common Knowledge 1. Meaning of SpO is the saturation percentage of oxygen in the blood, so called O concentration in the blood; it is defined by the percentage of oxyhemoglobin (HbO ) in the total hemoglobin of the arterial blood.
  • Page 26 User Manual for Fingertip Oximeter and deoxygenated hemoglobin (Hb) have different absorption character in the spectrum range from red to infrared light (600nm~1000nm wavelength), by using these characteristics, SpO can be determined. SpO measured by this oximeter is the functional oxygen saturation -- a percentage of the hemoglobin that can transport oxygen.
  • Page 27 User Manual for Fingertip Oximeter 3. Factors affecting SpO measuring accuracy (interference reason)  Intravascular dyes such as indocyanine green or methylene blue  Exposure to excessive illumination, such as surgical lamps, bilirubin lamps, fluorescent lights, infrared heating lamps, or direct sunlight. ...
  • Page 28 User Manual for Fingertip Oximeter 4. Factors causing low SpO Measuring value (pathology reason)  Hypoxemia disease, functional lack of HbO  Pigmentation or abnormal oxyhemoglobin level  Abnormal oxyhemoglobin variation  Methemoglobin disease  Sulfhemoglobinemia or arterial occlusion exists near sensor ...
  • Page 29 User Manual for Fingertip Oximeter Table 1 Guidance and manufacturer’s declaration - electromagnetic emissions The device is intended for use in the electromagnetic environment specified below. The user of this device should assure that it is used in such an environment. Compli Electromagnetic Emissions test...
  • Page 30 User Manual for Fingertip Oximeter Table 2 Guidance and manufacturer’s declaration - electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The user of this device should assure that it is used in such an environment. Compli Electromagnetic IEC 60601...
  • Page 31 User Manual for Fingertip Oximeter <5 % UT Voltage (>95 % dip dips, short in UT) interruptions for 0.5 cycle and voltage 40 % UT variations (60 % dip in power supply input for 5 cycles lines 70 % UT (30 % dip in 61000-4-11 for 25 cycles...
  • Page 32 User Manual for Fingertip Oximeter Table 3 Guidance and manufacturer’s declaration – electromagnetic immunity The device is intended for use in the electromagnetic environment specified below. The user of this device should assure that it is used in such an electromagnetic environment. Compli Immunity Electromagnetic...
  • Page 33 User Manual for Fingertip Oximeter Where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer and d is the recommended separation distance in meters (m). Field strengths from fixed RF transmitters, as determined by an electromagnetic site survey ,a should be less...
  • Page 34 User Manual for Fingertip Oximeter a: Field strengths from fixed transmitters, such as base stations for radio (cellular / cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, and electromagnetic site survey should be considered.
  • Page 35 User Manual for Fingertip Oximeter Table 4 Recommended separation distances between portable and mobile RF communications equipment and the device The device is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The user of this device can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and this device as recommended below, according...
  • Page 36 User Manual for Fingertip Oximeter For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer.
